Conditions for execution of cutting data
The following conditions affect the automatic operation of the machine
being executed according to the cutting data stored at the respective
stations:
• When “0” is set in either of the L and P fields for a given station, the
machine skips the station and goes to the next station.
• When “0” is set in both of the L and P fields for a given station, the
machine ends its automatic operation at the station.
• When the P and C fields display the same value for a given station,
the machine skips the station and goes to the next station.
Example of data execution
ST.
field
L
field
P
field
C
field
Operating status Execution condition
1 100.0 10 0 Started and executed Automatic operation is started
2 200.0 0 0 Skipped P field is set to “0”
3 0.0 10 0 Skipped L field is set to “0”
4 400.0 40 40 Skipped 40 pieces are already cut
5 500.0 50 0 Executed
6 0.0 0 0 Ended L and P fields are both set to “0”
7 700.0 70 0 Started and executed Automatic operation is resumed
8 800.0 80 0 Executed
9 0.0 0 50 Ended L and P fields are both set to “0”
When the cutting data are stored at the stations 1 to 9 as shown above,
• Displaying the station number 1 and starting the machine cut the work
at the station 1, skip the stations 2 to 4, cut the work at the station 5,
and end the automatic operation.
• Displaying the station number 7 and starting the machine cut the work
at the stations 7 and 8 and end the automatic operation.
