IV-11
ADJUSTING POSITION OF WIRE BRUSH
WARNING
O Never try to adjust the wire brush on the
saw blade when the saw blade is running.
It is dangerous if your hands or clothing
are caught in the running saw blade.
NOTE
O The wire brush is consumable. If it is worn, remove the hexagon nut
securing it to the shaft, and change it for a new one.
Adjust the position of the wire brush so that the wire bristles just touch
the gullet as described below. Make this adjustment not only after
changing the saw blade, but also at regular intervals.
1 Loosen the wire brush
lock lever.
2 Adjust the position of
the wire brush so that
the wire bristles just
touch the gullet, and
tighten the wire brush
lock lever in that
position.
WIRE BRUSH
COVER
WIRE BRUSH
LOCK LEVER
To Next Page
