Amada HFA-400 - Checking Cutting Data (Calling Station); Changing Cutting Data

IV-33
Checking cutting data (calling station)
When calling the station whose cutting data are to be checked, move
the cursor to the ST. field and enter the number for the station in the ST.
field as you did when entering and storing the cutting data for the
station.
The length and quantity of pieces to be cut as stored at the station
number are displayed in the L and P fields, respectively. The C field
displays the quantity of pieces cut during the last automatic operation.
NOTE
O Before starting the automatic operation of the machine, check the cutting data
of all stations.
Changing cutting data
Change the stored cutting data as described below.
NOTE
O The cutting data can be changed during the automatic operation of the
machine, except that the cutting data of the station currently being executed
cannot be changed.
1 Enter with the numeric keys the number for the station whose
cutting data you want to change, and press the ENT key.
2 To change the cutoff length, move the cursor to the L field with the
cursor keys. To change the quantity of pieces to be cut, move the
cursor to the P field with the cursor keys.
3 Enter the appropriate value with the numeric keys, and press the
ENT key.
4 To reset the quantity of pieces already cut, move the cursor to the
C field with the cursor keys. In this condition, the quantity of
pieces already cut may be reset by either of the following methods:
(a) Press the CLR key and the ENT key.
(b) Press the numeric key “0” and the ENT key.
5 This stores the new cutting data.
Canceling cutting data
When canceling the cutting data stored at a station, call the station first.
Set either the L or P field to “0”, and press the ENT key.
The automatic operation of the machine skips the station.
NOTE
O When the L and P fields are both set to “0” for a given station, the automatic
operation of the machine is stopped at the station.
