IV-40
OPERATION
WARNING
O Before starting the operation of the
machine each time, be sure to check that
there are no people and obstacles around
the machine.
O Never take your eyes off the machine or
lean on the machine during operation. Be
ready for a situation that demands
immediate attention to prevent an
accident.
O Never touch the running saw blade or chip
conveyor. It is dangerous if your hands
or clothing are caught in the running saw
blade or chip conveyor.
O Never try to adjust the wire brush on the
saw blade or remove chips when the saw
blade is running. It is dangerous if your
hands or clothing are caught in the
running saw blade.
O Be sure to check that the flow rate of the
cutting fluid is adjusted to a proper
degree. If the cutting fluid is not supplied
in sufficient amounts, the life of the saw
blade may be markedly shortened. If the
cutting operation is continued in this
condition, a fire may occur.
Manual operation
STARTING CUTTING
Position the work and cut it once during the manual operation as
described below.
1 Check again that:
• The sawhead downfeed speed and cutting pressure are
properly set.
• The saw blade running speed is properly set.
• The saw blade inserts are closed.
• The wire brush is properly positioned.
• The flow rate of the cutting fluid is properly adjusted.
• The work is securely clamped.
2 Turn the AUTO/MANUAL switch to MANUAL.
3 Press the BLADE DRIVE button to start cutting the work.
The saw blade starts running, and the sawhead rapidly lowers until
the quick approach feeler touches the work. The sawhead then
lowers at the preset downfeed speed.
