Amada HFA-400 - Every Month; Cleaning

VI-5
Every month
CLEANING
Chip box
Clean the chip box as described below.
1 Pull up the handle of
the chip chute to
remove the entire chip
chute.
2 Remove the chip box
fixing lever, pull out
the chip box, and
remove it upward.
3 Remove the chips
from the chip box, and
clean the filter.
Clear the filter of
foreign matter with an
air gun. If oil is
deposited on the filter,
wash it away with
kerosene.
4 Replace the filter in
the grooves of the
chip box without any
clearance.
5 Replace the chip box
in the cutting fluid
pan, and apply the
chip box fixing lever to
the cutting fluid pan
hook. Unless the
fixing lever is applied
to the hook, the chip
box may move.
6 Replace the chip
chute in the cutting
fluid pan.
