IV-18
Semiautomatic positioning function
During the manual operation of the machine, its semiautomatic
positioning function automatically moves the rear vise backward for the
preset cutoff length.
SETTING CUTOFF LENGTH
Set the cutoff length as described below.
1 Move the cursor to the
ST. field with the
cursor keys.
2 Press the numeric key
“0” and the ENT key
to call the station 0 in
the ST. field and move
the cursor to the L
field.
The station 0 is exclusively used for the semiautomatic positioning
function, and nothing can be entered in the P and C fields.
If the station 0 was used before, the cutoff length preset then is
shown in the L field.
3 Enter the cutoff length
in the range of 5.0 to
400.0 mm {0.197 to
15.748 in.} with the
numeric keys.
NOTE
O With the semiautomatic positioning function, allow for the saw blade
kerf.
4 Press the ENT key to store the cutoff length in memory.
