Amada HFA-400 - Inserting Interrupt Station Between Stations to be Executed

IV-48
INSERTING INTERRUPT STATION BETWEEN STATIONS TO BE
EXECUTED
Example:
field:
field:
field:
field:
field:
field:
field:
field:
field:
Second piece being cut
1
Insert the following cutting data as interrupt station between the stations
1 and 2 under the above conditions:
Cutoff length (L field): 10 mm
Quantity to be cut (P field): 2 pieces
When the interrupt station is set as described on the next page, the
numbers of the stations become as shown below. After the execution
of the station 1, the interrupt station begins to be executed.
The interrupt station is stored as the new station 2, and the former
station 2 and subsequent stations are incremented by one each in
number.
field:
field:
field:
field:
field:
field:
field:
field:
field:
field:
field:
field:
After executing the interrupt station, the machine continues to execute
the new station 3 (former station 2).
