I-11
Tank capacity 40 liters {10.6 US gal}
Pump type Variable-volume piston pump
Pump capacity 22 liters/min {5.8 US gal/min}
Hydraulic
Pressure setting 3.5 MPa {35 kgf/cm
2
or 498 psi}
Automatic
Hydraulic automatic rise
(automatic stop at upper limit)
Up
Manual Inching up by pushbutton operation
Rise height setting Automatic setting with quick approach feeler
Automatic Rapid approach with quick approach feeler
Down
Manual Inching down by pushbutton operation
Depth-of-cut control Hydraulic pressure-flow control valve
Saw blade control
Slip detection
Automatic stop at overload, jamming, or
breakage
Type (capacity)
Hydraulic shuttle type, maximum stroke length
of 400 mm {15.75 in.}, standby position
selectable
Work feed
Remnant length
[for clamp clearance of 10
mm {0.4 in.}]
Single cutting: 76 mm {2.99 in.}**
Stack cutting: 214 mm {8.43 in.}
Chip disposal
Chip conveyor
(automatic hydraulic screw type)
Table height 800 mm {31.5 in.}
Saw blade twist angle
60°
Allowable loading mass on machine 2500 kg {5510 lb}
Machine dimensions (W × D × H)
2472 × 2646 × 2522 mm
{97.3 × 104.2 × 99.3 in.}
Machine mass Approx. 2200 kg {4850 lb}
**When the machine is equipped with an optional head-end positioning function, the remnant
must be 150 mm {5.91 in.} or longer when work with a diameter or height of less than 12 mm
{0.47 in.} is to be fed.
