III-11
[25] FLOW CONTROL dial
Used to adjust the downfeed speed of the sawhead for cutting.
Turn the dial clockwise to increase the downfeed speed and
counterclockwise to decrease the downfeed speed. Set this dial in
accordance with the CUTTING PRESSURE CONTROL dial.
NOTE
O The downfeed speed of the sawhead changes with the setting of the
CUTTING PRESSURE CONTROL dial even if the FLOW CONTROL dial
remains at a certain position. The sawhead increases in downfeed speed
when the CUTTING PRESSURE CONTROL dial is turned clockwise and
decreases in downfeed speed when the CUTTING PRESSURE CONTROL
dial is turned counterclockwise. When you have turned the CUTTING
PRESSURE CONTROL dial, also adjust the FLOW CONTROL dial.
O When you have turned the CUTTING PRESSURE CONTROL dial clockwise,
turn the FLOW CONTROL dial counterclockwise. Similarly when you have
turned the CUTTING PRESSURE CONTROL dial counterclockwise, turn the
FLOW CONTROL dial clockwise.
When the cutting operation is performed at high pressure, at high downfeed
speed and at higher than standard cutting rate, the machine and saw blade
may be overloaded, and the cutting accuracy and the machine and saw blade
life may be adversely affected.
