IV-14
4 Press and hold the
REAR VISE
BACKWARD button
to move the rear vise
to the backward limit.
5 Loosen the lock
levers above the
vertical rollers, and
move the vertical
rollers by hand to
make their distance
greater than the width
of the work.
BACKWARD
LIMIT
6 Gently place the work
on the rear vise bed.
Check that the head
end of the work
projects about 50 mm
{2 in.} from the front
end of the rear vise
toward the front vise.
WORK
ABOUT
50 mm
{2 in.}
7 Press and hold the
REAR VISE CLOSE
button to clamp the
work with the rear
vise.
8 Move the vertical
rollers by hand
against the work, and
securely tighten the
lock levers.
