Analog way VIO 4K User Manual

61
www.analogway.com
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
USER MANUAL
Plug type
Formats
Signals
HDMI 1.4a
SDTV
YCbCr ITU-R BT.601
RGB Full scale (0-255)
RGB Limited scale (16-235)
EDTV
YCbCr ITU-R BT.601
RGB Full scale (0-255)
RGB Limited scale (16-235)
HDTV
YCbCr ITU-R BT.709
RGB Full scale (0-255)
RGB Limited scale (16-235)
UHDTV/4K
(up to 30Hz)
YCbCr ITU-R BT.709
RGB Full scale (0-255)
RGB Limited scale (16-235)
Computer
YCbCr ITU-R BT.601
RGB Full scale (0-255)
RGB Limited scale (16-235)
DisplayPort 1.2
SDTV
YCbCr ITU-R BT.601
RGB Full scale (0-255)
RGB Limited scale (16-235)
EDTV
YCbCr ITU-R BT.601
RGB Full scale (0-255)
RGB Limited scale (16-235)
HDTV
YCbCr ITU-R BT.709
RGB Full scale (0-255)
RGB Limited scale (16-235)
UHDTV/4K
(up to 30Hz)
YCbCr ITU-R BT.709
RGB Full scale (0-255)
RGB Limited scale (16-235)
Computer
YCbCr ITU-R BT.601
RGB Full scale (0-255)
RGB Limited scale (16-235)
3G-SDI
SDTV
SMPTE 259M-C (YCbCr ITU-R BT.601 4:2:2)
HDTV
SMPTE ST296 (720p YCbCr ITU-R BT.709 4:2:2)
SMPTE 274M (1080i/1080p YCbCr ITU-R BT.709 4:2:2)
SMPTE ST2048 (2K YCbCr ITU-R BT.709 4:2:2)
6G-SDI
UHDTV/4K
(up to 30Hz)
SMPTE ST2036 (2K YCbCr ITU-R BT.709, ITU-R BT.2020 4:2:2)
SMPTE ST2048 (4K YCbCr ITU-R BT.709, ITU-R BT.2020 4:2:2)
OPTICAL SFP
Slot (NMSA)
SDTV
SMPTE 259M-C (YCbCr ITU-R BT.601 4:2:2)
HDTV
SMPTE ST296 (720p YCbCr ITU-R BT.709 4:2:2)
SMPTE 274M (1080i/1080p YCbCr ITU-R BT.709 4:2:2)
SMPTE ST2048 (2K YCbCr ITU-R BT.709 4:2:2)
UHDTV/4K
(up to 30Hz)
SMPTE ST2036 (2K YCbCr ITU-R BT.709, ITU-R BT.2020 4:2:2)
SMPTE ST2048 (4K YCbCr ITU-R BT.709, ITU-R BT.2020 4:2:2)
