150
www.analogway.com
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
USER MANUAL
A Frame is a 24-bit RGB still picture whose maximum pixel size is 8192x4320 pixels.
You can use frames to:
Capture the active input or the output (capture video);
Display a foreground frame (quick-frame function);
Create a nice transition effect (frame transitions);
Display a background when no input source is selected (black frame).
The currently supported frame formats are:
BMP,
JPEG,
PNG.
You can import and export frames to and from the device via the Frame Library:
Importing frames will allow you to use frames directly available on the device;
Exporting frames will allow you to transfer frames to other devices.
You can also create frame captures from your video inputs and outputs (SEE: Creating frame captures).
To import a frame to the library:
Front Panel
NOTE: You will need to a USB key to import frames via the front panel.
Before you start:
Prepare a USB key with the frames you wish to import.
Plug-in the USB key into the USB HOST port (located on the front panel).
Wait until the device is properly recognized and then proceed to import frames as described below.
1. Enter the FRAME menu on the Front Panel interface.
2. Select IMPORT to access USB device browser.
3. In the USB device browser, browse for the file to import.
TIP: Use the ENTER and EXIT-MENU keys to navigate through folders.
8 Frame management
8.1 What is a frame?
8.2 Supported frame formats
8.3 Importing and exporting frames
