201
www.analogway.com
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
USER MANUAL
TIP: When editing the screen, click on the Audio button (located in the screen toolbar) to access the Quick Audio
window and adjust the output audio (master volume/mute) (SEE: Controlling the audio).
Related topics:
VIO 4K Audio Block Diagram
Prelistening to audio content
Selecting the SDI audio output mode
The VIO 4K allows you to add an optional XLR audio system interface expansion card to create new S/PDIF
and AES3 audio inputs. This way you can take the most of XLR audio systems directly available on your VIO
4K unit.
To adjust the XLR audio input settings:
Front Panel
1. Enter the AUDIO menu on the Front Panel interface.
2. Select the Option Card Settings meu.
3. Select the XLR In Mode for the optional XLR card.
10.7 Adjusting the XLR audio
