Ref. OPT-4K60P-SDI-VIO4K
The OPT-4K60P-SDI-VIO4K expansion card is a high-performance I/O video interface for the VIO 4K able to
support formats up to UHD/4K60Hz 4:4:4 and featuring DisplayPort 1.2, HDMI 2.0, 12G-SDI, 12G-SFP and
Quad-Link 3G-SDI connectivity.
HDMI 2.0 supports up to 18Gbps of bandwidth allowing resolutions up to UHD/4K@60 4:4:4 8 bits,
2560x1440@60 4:4:4 10 bits or 2560x1440@120 4:4:4 8 bits. HDMI 2.0 is compliant with HDCP 1.4 and HDCP
2.2 and supports RGB444, YCbCr ITU-R BT.601, ITU-R BT.709 and ITU-R BT.2020 color spaces.
DisplayPort 1.2 supports up to 21.6Gbps of bandwidth allowing resolutions up to UHD/4K@60 4:4:4 10 bits.
DP 1.2 is compliant with HDCP 1.3 and supports RGB444, YCbCr ITU-R BT.601 and ITU-R BT.709.
Quad 3G-SDI connections (four quadrants or SMPTE 425-5) can be used either as an input or as an output
and support resolutions up to 2160p60 (4:2:2 10 bits).
12G-SDI and 12G-SFP connections can be used either as an input or as an output and support resolutions up
to 2160p60 (4:2:2 10 bits).
TIP: When equipped with one of the 4K60P expansion video card, the VIO 4K may deliver or receive UHDTV formats
using the YCbCr ITU-R BT.2020 color space instead of the YCbCr ITU-R BT.709 color space used for HDTV formats.
Choose the internal processing color standard to optimize the color space gamut and limit useless color space conversions.
