62
www.analogway.com
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
PROGRAMMER’S GUIDE
USER MANUAL
SEE also: Custom Formats
Plug type
Formats
Signals
HDMI 2.0
UHDTV/4K
(up to 60Hz)
YCbCr ITU-R BT.601, ITU-R BT.709, ITU-R BT.2020
RGB Full scale (0-255)
RGB Limited scale (16-235)
DisplayPort 1.2
UHDTV/4K
(up to 60Hz)
YCbCr ITU-R BT.601, ITU-R BT.709, ITU-R BT.2020
RGB Full scale (0-255)
RGB Limited scale (16-235)
12G-SDI
UHDTV/4K
(up to 60Hz)
SMPTE ST2036 (2K YCbCr ITU-R BT.709, ITU-R BT.2020 4:2:2)
SMPTE ST2048 (4K YCbCr ITU-R BT.709, ITU-R BT.2020 4:2:2)
OPTICAL SFP
Slot (NMSA)
UHDTV/4K
(up to 60Hz)
SMPTE ST2036 (2K YCbCr ITU-R BT.709, ITU-R BT.2020 4:2:2)
SMPTE ST2048 (4K YCbCr ITU-R BT.709, ITU-R BT.2020 4:2:2)
Related topics:
Expansion interfaces
The output status provides information on the current output configuration.
Available output status information includes:
Format Mode: Current mode used to set up the format.
Possible output format modes include:
INTERNAL REF.
Internal reference format mode
AUTO EDID
FORMAT
Automatic format mode based on EDID
FRAMELOCK
Framelock format mode
GENLOCK
Genlock format mode
Format: Currently applied format.
Rotation: Current output rotation.
AOI: Current active area of your display in the output format.
Size: AOI horizontal x vertical dimensions (in pixels).
Position: AOI horizontal, vertical start offset (in pixels).
Plug Status: Output plug status.
List of possible status for each plug include:
NOT AVAILABLE
Plug is not available for this output
ACTIVE
Plug is active for this output
ACTIVE (WARNING EDID INVALID)
Plug is active but monitor EDID is invalid
DISABLED FOR HDCP REASON
Plug is disabled for this output because it does not have the
HDCP capability
6.2.1 Additional outputs supported with video expansion interfaces
6.3 Checking the output status
