USER MANUAL
NOTE: You can enable and disable pattern display whenever required by checking/unchecking the Hide check-box. All pattern
adjustments will be remembered when enabling/disabling pattern display.
Related topics:
Checking the output status
Creating custom formats
Using the Genlock reference
You can monitor the output both from the Front Panel and the Web RCS interfaces.
Monitoring the output will allow you to check your output adjustments before the connection setup is
complete for example.
To monitor the output:
Front Panel
1. Press the Monitor button in the Front Panel interface.
2. Scroll down and select STANDARD OUTPUT to enable output monitoring on the front panel LCD
screen (press the EXIT-MENU button to exit monitoring).
6.5 Monitoring the output
