To specify the format to use on the Genlock reference input:
Front Panel
1. Enter the OUTPUTS menu on the Front Panel interface.
2. Select GENLOCK REFERENCE to access the Genlock input setup menu.
3. Select OVERLOAD DETECTED FORMAT.
4. Scroll down the list of formats detected on the Genlock input and select the format to use on the
Genlock reference input.
Web RCS
1. Go to the Setup menu on the Web RCS interface.
2. Click on the OUTPUTS tab to access the outputs setup page.
3. In the left side toolbar, select Genlock Ref to access the Genlock input settings page.
4. Under Overload Detected Format, select the format to use on the Genlock reference input.
To set up the format using the Genlock reference input:
SEE: Genlock to the dedicated input
Related topics:
• Output format
• Screens
• Audio management
• Custom formats
• Configuration backup
