Optional TLVOptional TLV
Use the drop-down menu to select a TLV type (Type, Length and Value), if
relevant. The possible types are: Data TLVData TLV and Test TLVTest TLV. If you select one of
the TLV types, LengthLength and ValueValue fields for specifying the ID will appear.
LengthLength
Only available if a Data TLVData TLV or Test Test TLVTest TLV has been selected. Allows you to
specify the length of the TLV.
ValueValue
Only available if a Data TLVData TLV or Test TLVTest TLV type has been selected. Allows you to
specify the value of the TLV. Note that for the Data TLVData TLV type, this field is an
entry field where you open an editor and type the value; for the Test TLVTest TLV type,
it is a drop-down menu.
LTM tabLTM tab
The LTMLTM tab contains the Link Trace Message parameters:
TTLTTL
Allows you to specify a TTL (Time to Live) value. Used to indicate whether or
not an LTM should be terminated by the receiver.
Trans IDTrans ID
Allows you to specify the transaction number for the LTM.
TST tabTST tab
The TSTTST tab contains the Test PDU parameters:
Frames to sendFrames to send
Allows you to specify the number of frames to be transmitted.
RateRate
Use the drop-down menu to select the rate at which frames are transmitted.
Optional TLVOptional TLV
Use the drop-down menu to select the Test TLVTest TLV type, if relevant. LengthLength and
ValueValue fields will then appear.
LengthLength
Only available if the Test TLV type has been selected. Allows you to specify the
length of the TLV.
ValueValue
Only available if the Test TLV type has been selected. Use the drop-down menu
to select the value of the TLV.
MCC tabMCC tab
The MCCMCC tab contains the Maintenance Communication Channel parameters:
OUIOUI
