Allows you to specify the Organizationally Unique Identifier for the
organization defining a specific format and meaning of ETH-MCC.
DataData
Allows you to specify any required additional information. The type of
information depends on the specific application of ETH-MCC.
LCK tabLCK tab
The LCKLCK tab contains the Locked parameters:
Client MEG levelClient MEG level
Allows you to specify the MEG level of the client MEG.
LCK rateLCK rate
Use the drop-down list to select the rate of the LCK frames being transmitted.
AIS tabAIS tab
The AISAIS tab contains the Alarm Indication Signal parameters:
Client MEG levelClient MEG level
Allows you to specify the MEG level of the client MEG.
AIS rateAIS rate
Use the drop-down menu to select the rate of the AIS frames being transmitted.
1DM tab1DM tab
The 1DM1DM tab contains the One-way Delay Measurement parameters:
TypeType
Use the drop-down menu to select the relevant operation type (On-demandOn-demand
operationoperation or Proactive operationProactive operation). The same 1DM frame format can be used for
both.
RateRate
Use the drop-down menu to select the rate at which 1DM frames are
transmitted.
Frames to sendFrames to send
Allows you to specify the number of frames to transmit.
Optional TLVOptional TLV
Use the drop-down menu to select a TLV type, if relevant. The possible types
are: Data TLVData TLV and Test TLVTest TLV. If you select one of the TLV types, LengthLength and
ValueValue fields for specifying the IDID will appear.
LengthLength
Only available if a Data TLVData TLV type has been selected. Allows you to specify the
length of the TLV.
ValueValue
