Only available if a Data TLVData TLV type has been selected. Allows you to specify the
value of the TLV. Note that for the Data TLVData TLVV type, this field is an entry field
where you open an editor and type the value.
IDID
Only available if a Test TLVTest TLV type has been selected. Allows you to specify the
value of the ID.
DMM tabDMM tab
The DMMDMM tab contains the Delay Measurement Message parameters:
TypeType
Use the drop-down menu to select the relevant operation type (On-demandOn-demand
operationoperation or Proactive operationProactive operation).
RateRate
Use the drop-down menu to select the rate at which DMM frames are
transmitted.
Frames to sendFrames to send
Allows you to specify the number of frames to transmit.
Delay thresholdDelay threshold
Allows you to specify a delay threshold that is used when a DMM test is active.
If the delay meets or exceeds that threshold, the user is alerted.
Optional TLVOptional TLV
Use the drop-down menu to select a TLV type, if relevant. The possible types
are: Data TLVData TLV and Test TLVTest TLV. If you select one of the TLV types, LengthLength and
ValueValue fields for specifying the ID will appear.
LengthLength
Only available if a Data TLVData TLV type has been selected. Allows you to specify the
length of the TLV.
ValueValue
Only available if a Data TLVData TLV type has been selected. Allows you to specify the
value of the TLV. Note that for the Data TLVData TLV type, this field is an entry field
where you open an editor and type the value.
IDID
Only available if a Test TLVTest TLV type has been selected. Allows you to specify the
value of the ID.
LMM tabLMM tab
The LMMLMM tab contains the Loss Measurement Message parameters:
RateRate
Use the drop-down menu to select the rate at which LMM frames are
transmitted.
Frames to sendFrames to send
