Wall ClockWall Clock
Grandmaster ClockGrandmaster Clock
Shows the port number of the currently selected foreign master.
Announce countAnnounce count
Shows the number of Announce Messages received from the currently selected
foreign master.
UTCUTC
Shows the current UTC time. Requires an external GPS receiver.
CurrentCurrent
Shows the current wall clock time.
UTC offsetUTC offset
Shows the offset between the wall clock time and the UTC time.
This is available when the GPS is used as reference.
IdentityIdentity
Shows the identity of the grandmaster.
ClassClass
Shows the class of the grandmaster. Ql is displayed together, depending on
SyncE Ql type, profile, and class value.
AccuracyAccuracy
Shows the accuracy of the grandmaster. The hexadecimal value of the accuracy
in the PTP packet data is displayed right-hand.
Variance ann/est.Variance ann/est.
Shows the offset variance of the grandmaster. Both the announced value and a
calculated estimate are shown (in s
2
).
Variance RawVariance Raw
Shows the offset variance of the grandmaster in hexadecimal.
Priority 1/2Priority 1/2
Shows priority 1 and 2 of the grandmaster.
Steps removedSteps removed
Shows the number of communication paths traversed between the local clock
and the grand master clock.
Time sourceTime source
Shows the time source. The hexadecimal value of the time source in the PTP
packet data is displayed right-hand.
UTC offsetUTC offset
Shows the UTC offset provided by Announce Message from the Groundmaster
clock.
flagfieldflagfield
Shows the flag field of the announce message in hexadecimal. To see details,
touch the button.
