Frame Field TriggerFrame Field Trigger
DefinitionDefinition
This is the default setting, which captures all frames. All other trigger setup
parameters are disabled.
Error
Frame capture starts when the error specified by Error TypeError Type drop-down menu
has occurred.
Field match
Frame capture starts if the field in transmitted frame matches to one defined
by Frame Field Trigger DefinitionFrame Field Trigger Definition.
Trigger positionTrigger position
Select the position of a trigger frame in the captured data.
Top
The trigger frame will be located at top of the captured data.
Middle
The trigger frame will be located at center of the captured data.
Error TypeError Type
The possible values are: Any TypeAny Type, FragmentFragment, Oversized or undersizedOversized or undersized,
OversizedOversized, UndersizedUndersized, FCS errorFCS error, Oversized & FCS errorOversized & FCS error and IP checksumIP checksum
errorerror.
Touching the left field opens the Field offsetField offset dialog box, which enables you to
specify a value between 0 and 15999 in the field.
Touching the center field opens the Pattern EditorPattern Editor dialog box, which enables
you to specify the relevant pattern in the field.
Capturing framesCapturing frames
Start/stop captureStart/stop capture
Touch the StartStart button to start the capturing. The button changes to the StopStop
button. Capture progress is shown in Buffer UsageBuffer Usage.
To stop the frame capture, touch the StopStop button.
Save capture dataSave capture data
When the capture is complete, you can save the captured data as a PCAP file,
which can be used by a variety of open-source decoding tools. You can also
save the data and then view them on the Network Master using Wireshark
application in Utilities.
Touching the SaveSave button allows you to create a PCAP file and view the data on
the Network Master. Touching the ViewView button allows you to view the data on
the Network master.
When saving capture files using the MX100001A MT1000A/MT1100A/MT1040A
Control Software, the destination folder is automatically set to the "Internal" folder of the
Network Master.
