This dialog box allows reading/writing information into the registers of the
optical transceiver via I
2
C (Inter-Integrated Circuit) interface.
Registers in the transceiver are defined in
SFF-8472 Specification for
Diagnostic Monitoring Interface for Optical Transceivers
and
SFF-8690
Specification for Tunable SFP+ Memory Map for ITU Frequencies
.
SFP Memory Map
Memory A0hMemory A0h shows information in Memory A0h.
Memory A2hMemory A2h shows information in Memory A2h.
Read/WriteRead/Write allows you to read or write values to the specified registers.
Read/WriteRead/Write
Read/WriteRead/Write allows you to read or write values to the specified registers.
Setup ModuleSetup Module
Touching the InitializeInitialize button initializes register values in the transceiver.
Read/WriteRead/Write
