AvailAvail
Shows
Availability
, which is the percentage of one-second in intervals that are
categorized as available. An available second occurs when the line is in the
available state. The available state begins at the onset of 10 consecutive non-
SES
eth
outcomes. A SES
eth
is defined as a second with a frame loss rate of 0.5
or more. See ITU-T Y.1563
Ethernet frame transfer and availability
performance
clause 9.
66..1111..33..44 Event LogEvent Log
Touching the Event LogEvent Log button in the navigation area displays the screen
providing the event log data. Refer to Event Log of SDH/SONET/PDH/DSn
BERT application.
66..1111..33..55 StatisticsStatistics
Touching the StatisticsStatistics button in the navigation area displays the screen
providing the statistics data. Refer to Statistics of Mon/Gen for the operation.
