Selecting the intervalSelecting the interval
timetime
If Ext. logExt. log is selected in IEEE1588v2 screen of Ethernet Frame Setup, the
IEEE1588v2 LogIEEE1588v2 Log button appears in the navigation area. Refer to IEEE1588v2
Log in "BERT" for the operation.
66..55..33..33 OAM LogOAM Log
The operation of OAM LogOAM Log screen is the same as that of BERT application.
Refer to OAM Log in BERT for the operation.
66..55..33..44 Event LogEvent Log
Touching the Event LogEvent Log button in the navigation area displays the screen
providing the event log data. Refer to Event Log of SDH/SONET/PDH/DSn
BERT application.
66..55..33..55 StatisticsStatistics
Touching the StatisticsStatistics button in the navigation area displays the screen shown
below.
This screen presents a detailed analysis of the test results. You can choose to
view either the total results from measurement start or the results of a specific
interval during the test. You can also zoom in on a specific result item. The
results can be displayed either in table (list) form or as a graph.
Selecting which results to viewSelecting which results to view
Touch the TotalTotal button to switch the total values measured in all interval times.
The start time of measurement is displayed on the button.
Touching the button in left side BackBack field shows the measured values in the
interval time. The end time of the interval is displayed on the button.
The CurrentCurrent button is displayed at left bottom when the measurement is
running. Touching the CurrentCurrent button shows the measured values in the current
interval time. The start time of the current interval is displayed on the button.
