Event Indication :
Event IDEvent ID
A 1-byte value set by the transmitter of an Event
Indication or a Synchronization Request to enable
identification of the acknowledge response.
Event TypeEvent Type Select a Event type.
Sequence NumberSequence Number
The Sequence Number is a 1-byte value that is
incremented each time the transmitter sends the
“Event Indication” with Event Type set to 0x00
(Fault(s) Indication).
Number ofNumber of
Faults/NotifFaults/Notif
Number of fault indications or notifications attached
in the same message.
Element IDElement ID
0 to FFFE: Vendor specific usage
FFFF: A fault or notification applicable for all
Elements
Raise/CeaseRaise/Cease
0: Raise a fault
1: Cease a fault
Fault/NotifFault/Notif
A 12-bit number indicating a fault or notification
divided between 2 bytes.
AdditionalAdditional
InformationInformation
Additional information regarding the
fault/notification for vendor specific usage.
When Event IndicationEvent Indication or User DefinedUser Defined is selected, the following is displayed.
EnableEnable
Selecting the checkbox enables to edit Message Header which locates between
Common Header and payload. When the checkbox is not selected, no Message
Header is added.
LengthLength
Enter a byte length of Message Header.
Custom patternCustom pattern
Touch the field to edit the pattern.
ImportImport: loads a pattern from a file.
ExportExport: saves the pattern to a file.
PayloadPayload
Payload typePayload type
Select the payload type.
