Test signal interfaceTest signal interface
Bit Rate Bit Rate **
1212..22..22 Electrical Performance and FunctionElectrical Performance and Function
*: Frequency accuracy depends on MT1040A internal reference clock
and external reference clock.
For details, refer to MT1040A specification values.
QSFP28,
QSFP+:
2 Slots (Port 1, Port 2)
SFF-8436, SFF-8472, SFF-8665 compliant
IEEE 802.3ba-2010 compliant
SFP, SFP+,
SFP28:
2 Slots (Port 1, Port 2)
SFF-8402, SFF-8431, SFF-8472 compliant IEEE 802.3by, IEEE 802.3ae-
2002, IEEE802.3-2008 compliant
RJ45: 2 Sockets (Port 1, Port 2)
IEEE802.3-2008 10BASE-T, 100BASE-TX, 1000BASE-T compliant
Auto MDI-X
10/100 Mbps Full/Half Duplex, 1000 Mbps Full Duplex
StandardStandard Bit RateBit Rate InterfacesInterfaces
10BASE-T: 12.5 Mbit/s RJ-45
100BASE-TX: 125 Mbit/s RJ-45
1000BASE-T: 1.25 Gbit/s RJ-45
100BASE-X: 125 Mbit/s SFP
1000BASE-X: 1.25 Gbit/s SFP
10GBASE-X: 10.3125 Gbit/s SFP+
25GbE: 25.781250000 Gbit/s × 1 Lane SFP28
40GbE: 10.312500000 Gbit/s × 4 Lanes QSFP+
100GbE: 25.781250000 Gbit/s × 4 Lanes QSFP28
OTU1: 2.666057143 Gbit/s SFP
OTU2: 10.709225319 Gbit/s SFP+
OTU1e: 11.049107143 Gbit/s SFP+
OTU2e: 11.095727848 Gbit/s SFP+
OTU1f: 11.270089286 Gbit/s SFP+
OTU2f: 11.317642405 Gbit/s SFP+
OTU3: 10.754603390 Gbit/s × 4 Lanes QSFP+
OTU3e1: 11.142743644 Gbit/s × 4 Lanes QSFP+
OTU3e2: 11.145838894 Gbit/s × 4 Lanes QSFP+
OTU4: 27.952493392 Gbit/s × 4 Lanes QSFP28
STM-1/OC-3: 155.52 Mbit/s SFP
STM-4/OC-12: 622.08 Mbit/s SFP
STM-16/OC-48: 2488.32 Mbit/s SFP
STM-64/OC-192: 9953.28 Mbit/s SFP+
1GFC: 1.0625 Gbit/s SFP
2GFC: 2.125 Gbit/s SFP
4GFC: 4.25 Gbit/s SFP
8GFC: 8.5 Gbit/s SFP+
10GFC: 10.51875 Gbit/s SFP+
16GFC: 14.025 Gbit/s SFP+
MU104011A 100G Multirate ModuleMU104011A 100G Multirate Module
