Link DetectionLink Detection
Login DetectionLogin Detection
Pattern DetectionPattern Detection
TransceiverTransceiver
BER TestBER Test
PerformancePerformance
Reflector modeReflector mode
Port modePort mode
Line rateLine rate
Clock ConfigurationClock Configuration
ContentContent
PatternPattern
CPRI LinkCPRI Link
Insertion timing
Manual, Burst
Signal Present, Sync Acquired, Link Status
Fabric Login, Port Login, ELP
Traffic, Pattern Sync, Pattern Error
Module Present
Transceiver Information
Alarm, Wavelength and bit rate, Compliance, Vendor Information, Output
Control
Power monitor
BERT:
Pattern bit count, Pattern errors, Frame loss, Frame loss seconds, Pattern loss
seconds, Jitter, Latency, Service disruption
Symbol Errors
Ordered Sets:
R_RDY, LR, LRR, NOS, OLS
Traffic:
Frames, Bytes
Errors:
IFG, CRC, Symbol, CRD, Terminate, Errored
Line rate, Frame rate, Throughput
Size Distribution
Test Mode:
Port to Port, Loopback
Test:
Throughput, Traffic Profile, Latency, Burst, Credit (Only for Loopback mode)
Supports Reflector application.
1212..55..55 CPRI/OBSAICPRI/OBSAI
Unframed: Off, Normal
CPRI Link: Off, Normal, Through
OBSAI Link: Off, Normal
CPRI: 614.4 Mbps, 1228.8 Mbps, 2457.6 Mbps, 3072.0 Mbps, 4915.2 Mbps,
6144.0 Mbps, 9830.4 Mbps, 10137.6 Mbps, 12165.12 Mbps, 24330.24 Mbps
OBSAI: 768 Mbps, 1536 Mbps, 3072.0 Mbps, 6144.0 Mbps
Timing Source
Internal clock
External clock
GPS
Received clock
Unframed, CPRI Link, OBSAI Link
PRBS 15, PRBS 20, PRBS 23, PRBS 29, PRBS 31, User 32 bit, OFF
Start up
