2-3 Front Panel Overview Instrument Overview
2-4 PN: 10580-00318 Rev. P S412E UG
Figure 2-3 shows the Menu key screen with shortcut icons for the installed measurement
modes and four rows of user-defined shortcuts to menus and setup files.
Press and hold down any touch-screen key for a few seconds to add a shortcut to this screen.
To add shortcut setup files (*.stp), open the recall menu and hold down on the file name for
several seconds. Then select the location for the shortcut.
User-defined shortcuts stay in memory until deleted. To delete or move a shortcut button,
press the Menu key, then press and hold the shortcut for approximately 3 seconds. The
Customize Button dialog box opens to allow a button to be deleted or moved. Press Esc to exit
the Menu shortcut display.
Figure 2-3. Menu Key Screen with User-Defined Shortcuts
Note
The Factory Default reset deletes all user created shortcut icons from the Menu
screen. Refer to the “Reset Menu” on page 5-16 for additional information.
