6-14 LCD Assembly Replacement Removal and Replacement

6-34 PN: 10580-00303 Rev. D Model MS20xxB MM

Installing the LCD:

9. Installation is the reverse of removal. Follow replacement instructions for each of the parts and

assemblies that were removed, as appropriate.

10. Close the case as described in Section “Case Reassembly:” on page 6-16.

Note

Pay attention to the routing of the LCD Backlight Cable. The cable must be positioned so that it is not

pinched when the unit is reassembled.
