Removal and Replacement 6-9 GPS (Option 31) Replacement

Model MS20xxB MM PN: 10580-00303 Rev. D 6-25

Note

The PCB Assembly that is shown in Figure 6-18 is not a VNA Master, but the removal steps are

appropriate.

Figure 6-18. Removing the GPS Module from the Main/VNA board (SPA board set to the side)

Remove

2 screws

Remove nut and washer

from GPS SMA connector
