Anyview A6 - Page 155

Patient monitor User’s manual
Chapter 16-6
from the patient monitoring data and the values which are inputted manually.
The parameters for monitoring, the identifications and the corresponding
measurement units are as shown in the following figure:
Parameter
Abbreviation
Unit
Cardiac output
C.O.
L/min
Heart rate
HR
bpm
Pulmonary artery wedge pressure
PAWP
mmHg
Mean artery pressure
MAP
mmHg
Mean pulmonary artery pressure
MPAP
mmHg
Central venous pressure
CVP
mmHg
End diastolic volume
EDV
mL
Height
Height
cm
Weight
Weight
kg
Parameters for calculation refer to the parameter values automatically
calculated by the selection of 【Calculation】. The parameters for calculation,
the identifications and the corresponding measurement units are as shown in
the following figure:
Parameter
Full Name
Unit
C.I.
Cardiac index
L/min/m
2
BSA
Body surface area
m
2
SV
Stroke volume
mL
SVI
Stroke index
mL/m
2
SVR
Systemic vascular resistance
dyn·s/cm
5
SVRI
Systemic vascular resistance
dyn·s·m
2
/cm
5
PVR
Pulmonary vascular resistance
dyn·s/cm
5
PVRI
Pulmonary vascular resistance
dyn·s·m
2
/cm
5
LCW
Left ventricular work
kg·m
LCWI
Left ventricular work index
kg·m/m
2
RCW
Right ventricular work
kg·m
RCWI
Right ventricular work index
kg·m/m
2
LVSW
Left ventricular stroke work
g·m
LVSWI
Left ventricular stroke work
g·m/m
2
RVSW
Right ventricular stroke work
g·m
RVSWI
Right ventricular stroke work
g·m/m
2
EF
Ejection fraction
%
