Patient monitor User’s manual
Chapter 1-14
4. VGA display connector
Connect to standard VGA display for secondary displaying.
5. Defibrillator synchronization connector
Connect to defibrillator for output defibrillator synchronization signal.
6. Auxiliary output connector
Connect to the device, such as oscillograph to output analog signals. It
also can be connected to nurse call system in hospital. When an alarm occurs,
outputting the nurse call signal to remind nurse.
7. Wired network connector
Standard RJ45 socket. It is used for connection with the central
monitoring system provided by manufacturer.
Connect to USB device, such as keyboard and mouse.
9. Auxiliary plug-in box connector (AnyView A3 doesn’t have the connector)
Connect to auxiliary plug-in box.
10. DC12V power input connector (Only AnyView A3 has the connector)
Equipment connected to the analog or digital interfaces must comply
with the respective IEC standards (e.g. IEC 60950 for data processing
equipment and IEC 60601-1 for medical equipment). Furthermore all
configurations shall comply with the current version of the standard
for SYSTEMS IEC 60601-1-1. Everybody who connects additional
equipment to the signal input part or signal output part configures a
medical system, and is therefore responsible that the system complies
with current version of the requirements of the system standard IEC
60601-1-1. If in doubt, consult the technical service department or
your local representative.
The operator could not touch these ports and the patient
