TABLE G1 - SENSOR BOX
66A. Sensor Box
66B. Sensor Box cable harness routing
66C. Sensor Box connector
TABLE H1
67. Intake duct control unit
68. Intake duct control unit connector
69. Rubber ring
TABLE H2
70. Clamp
71. Intake duct control unit cable harness routing
RSV4 Factory a-PRC Electrical system
ELE SYS - 139
