CAUTION
THERE IS ONE SPARE FUSE (I).
Control unit
Removal
•
Remove the fuel tank.
•
Disconnect both control unit connec-
tors
•
Unscrew and remove the three screws.
•
Remove the control unit.
NOTE
WHEN REFITTING THE CONNECTORS, THE SLIDES MUST MOVE FREELY TO THE END OF
STROKE, WHICH HELPS WITH THE INSERTION OF THE CONNECTOR: YOU MUST HEAR THE
RELEASE OF THE RETAINING TANG AT THE END OF STROKE.
Electrical system RSV4 Factory a-PRC
ELE SYS - 154
