30
Line, Sub-line Parameter Setting,
basic
Setting,
range
Authorization
98 17 Connection, door open 12 1-99 Factory
98 20 Connection of safety
switch, door closing
(FD1810)
13 1-99 Factory
98 21 Connection pedal (FD1810) 14 1-99 Factory
Line 99: Connection outputs
99 01 Conn., pressure pump 6 1-99 Factory
99 02 Conn., steam generator 7 1-99 Factory
99 03 Conn., cold water 1 1-99 Factory
99 04 Conn., hot water 2 1-99 Factory
99 05 Connection soft water 8 1-99 Factory
99 06 Connection PE system
(rotating nozzle)
14 1-99 Factory
99 07 Connection SP system
(spray nozzle)
13 1-99 Factory
99 08 Connection extra nozzle 15 1-99 Factory
99 10 Connection pump, descaler 8 1-99 Factory
99 11 Connection pump chemical
agent
7 1-99 Factory
99 12 Connection pump rinse-aid 5 1-99 Factory
99 13 Connection pump, process
agent
10 1-99 Factory
99 14 Connection pump spray
agent
9 1-99 Factory
99 15 Connection, extra element,
steam generator
12 1-99 Factory
99 16 Connection, condensate
cooler
3 1-99 Factory
99 17 Connection, external
cooling
4 1-99 Factory
99 23 Connection relay corresp.
to yellow LED
16 1-99 Factory
99 24 Connection relay corresp.
to red LED
15 1-99 Factory
99 25 5LPÀXVKLQJYDOYH For future use
99 26 Process active/Cooling fan
CPU
16 1-99 Factory
