TM 9-4935-601-14-7&P
Model 8640B
Table 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
A5K1 0490-1078 1 RELAY-REED 1A .5A 200V CONT 5V-COIL 28480 0490-1078
A5MP1 4040-0750 EXTRACTOR-PC BD RED POLYC .062-BD-THKNS 28480 4040-0750
1480-0073 PIN:DRIVE 0.250” LG 00000 OBD
A5MP2 4040-0756 1 EXTRACTOR-PC BOARD, WHITE 28480 4040-0756
1480-0073 PIN:DRIVE 0.250” LG 00000 OBD
A5Q1 1854-0221 2 TRANSISTOR-DUAL NPN PD=750MW 28480 1854-0221
45Q2 1854-0221 TRANSISTOR-DUAL NPN PD=750MW 28480 1854-0221
A5Q3 1854-0404 4 TRANSISTOR NPN SI TO-18 PD=360MW 28480 1854-0404
A5Q4 1854-0404 TRANSISTOR NPN SI TO-18 PD=360FW 28480 1854-0404
A5Q5† 1853-0038 4 TRANSISTOR PNP SI TO-39 PD=1W FT=100MHZ 28480 1853-0038
1205-0011 3 HEAT-DISSIPATOR SGL TO-5/TO-39 PKG 28480 1205-0011
1200-0173 12 INSULATOR-XSTR TO-5 .075-THK 28480 1200-0173
A5Q6† 1853-0038 TRANSISTOR PNP SI TO-39 PD=1W FT=100MHZ 28480 1853-0038
1205-0011 HEAT-DISSIPATOR SGL TO-5/TD-39 PKG 28480 1205-0011
1200-0173 INSULATOR-XSTR TO-5 .075-THK 28480 1200-0173
A5Q7† 1853-0038 TRANSISTOR PNP SI TO-39 PD-1W FT=100MZ 28480 1853-0038
1200-0173 INSULATOR-XSTR 70-5 .075-TH1 28480 1200-0173
A5Q8† 1854-0039 1 TRANSISTOR NPN 2N3053 SI TO-5 PD=1W 04713 2N3053
1205-0011 HEAT-DISSIPATOR SGL TO-5/TO-39 PKG 28480 1205-0011
1200-0173 INSULATOR-XSTR TO-5 .075-THK 28480 1200-0173
A5Q9† 1854-0022 2 TRANSISTOR NPN SI TO-39 PD=700MW 07263 S17843
1200-0173 INSULATOR-XSTR TO-5 .075THK 28480 1200-0173
A5Q10 1854-0237 2 TRANSISTOR NPN SI TO-66 PD-20W FT-10MHZ 04713 2N3738
0510-0002 2 PRESS-IN NUT 6-32 .062-LG 28480 0510-0002
1205-0085 2 HEAT-DISSIPATOR SGL TO-49 PKG 28480 1205-0085
2360-0199 2 SCREW-MACH 6-32 .438-IN-LG PAN-HD-POZI 28480 2360-0199
2420-0003 2 NUT-HEX-DBL-CHAM 6-32-THD .094-THK 28480 2420-0003
2190-0018 2 WASHER-LK HLCL NO.-6 .141-IN-IC 28480 2190-0018
2190-0007 2 WASHER-LK INTL T NO.-6 .141-IN-ID 78189 1906-00
A5Q11† 1853-0012 1 TRANSISTOR PNP 2N29046A SI TO-5 PD-600MW 01295 2N2904A
1200-0173 INSULATOR-XSTR TO-5 .075-THK 28480 1200-0173
A5Q12 1854-0237 TRANSISTOR NPN SI TO-66 PD=20W FT-100MHZ 04713 2N3738
0510-0002 PRESS-IN NUT 6-32 .062-LG 28480 0510-0002
1205-0085 HEAT-DISSIPATOR SGL TO-49 PKG 28480 1205-0085
2360-0199 SCREW-MACH 6-32 .438-IN-LG PAN-HD-POZI 28480 2360-0199
2420-0003 NUT-HEX-DBL-CHAM 6-32-THD .094-THK 28480 2420-0003
2190-0018 WASHER-LK INTL T NO.-6 .141-IN-ID 28480 2190-0018
2190-0007 WASHER-LK INTL T NO.-6 .141-IN-ID 78189 1906-00
A5R1 0698-3162 3 RESISTOR 46.4K 1% .125W F TC=0+-100 16299 C4-1/8-T0-4642-F
A5R2 0757-0180 2 RESISTOR 31.6 1% .125W F TC=0+-100 24546 C5-1/4-T0-31R6-F
A5R3 0757-0403 4 RESISTOR 121 1% .125W F TC=0+-100 24546 C4-1/8-T0-121R-F
A5R4 0757-0290 3 RESISTOR 6.19K 1% .125W F TC=0+-100 19701 MF4C1/8-T0-6191-F
A5R5 0757-0317 2 RESISTOR 1.33K 1% .125W F TC=0+-100 24546 C4-1/8-T0-1331-F
A5R6 0698-3132 3 RESISTOR 261 1% .125W F TC=0+-100 16299 C4-1/8-T0-2610-F
A5R7 0698-3410 1 RESISTOR 3.16K 1% .5W F TC=0+-100 24546 NA6
A5R8 2100-3164 1 RESISTOR-TRMR 10 20% C SIDE-ADJ 17-TURN 32997 3006P-1-100
A5R9 0698-0085 4 RESISTOR 2.61K 1% .125W F TC=0+-100 16299 C4-1/8-T0-2611-F
A5R10 0757-0317 RESISTOR 1.33K 1% .125W F TC=0+-100 24546 C4-1/8-T0-1331-F
A5R11 0698-3132 RESISTOR 261 1% 125W F TC=0+-100 16299 C4-1/8-T0-2610-F
A5R12 0757-0290 RESISTOR 6.19K 1% .125W F TC-0-100 19701 MF4C1/8-T0-6191-F
A5R13 0757-0180 RESISTOR 31.6 1% .125W F TC=0+-100 24546 C5-1/4-T0-31R6-F
A5R14 0757-0403 RESISTOR 121 1% .125W F TC=0+-100 24546 C4-1/8-T0-121R-F
A5R15 0698-3162 RESISTOR 46.46K 1% 125W F TC=0+-100 16299 C4-1/8-T0-4642-F
A5R16 0757-0401 6 RESISTOR 100 1% .125w F TC=0+-100 24546 C4-1/8-T0-101-F
A5R17 0698-3446 1 RESISTOR 383 1% .125W F TC=0+-100 16299 C4-1/8-T0-383R-F
A5R18 0698-3132 RESISTOR 261 13 .125W F TC=0+-100 16299 C4-1/8-T0-2610-F
A5R19 0757-0401 RESISTOR 100 1% .125W F TC=0+-100 24546 C41/8-T0-101-F
A5R20 0757-0346 RESISTOR 10 1% .125W F TC=0+-100 24546 C4-1/8-T0-10R0-F
A5R21 NOT ASSIGNED
A5R22 0698-3430 1 RESISTOR 21.5 1% .125W F TC=0+-100 03888 PME55-1/8-T0-21R54
A5R23 2100-3154 RESISTOR-TRNR 1K 10% C SIDE-ADJ T17-TURN 32997 3006P-1-102
A5R24 0757-0280 RESISTOR 1K 1% .125W F TC=0+-100 24546 C4-1/8-T0-1001-F
A5R25 0757-0280 RESISTOR 1K 1% .125W F TC=0+-100 24546 C4-1/8-T0-1001-F
A5R26 0757-0346 RESISTOR 10 1% .125W F TC=0+-100 24546 C4-1/8-T0-10R0-F
A5R27 0757-0441 2 RESISTOR 8.25K 1% 125W F TC=0+-100 24546 C4-1/8-T0-8251-F
A5R28 0757-0440 3 RESISTOR 7.5K 1% .125W F TC=0+-100 24546 C4-1/8-T0-7501-F
A5R29 0698-3158 1 RESISTOR 23.7K 1% .125W F TC=0+-100 16299 C4-1/8-T0-2372-F
A5R30 0757-0443 4 RESISTOR 11K 1% .125W F TC=0+-100 24546 C4-1/8-T0-1102-F
A5R31 0757-0442 RESISTOR 10 1% .125W F TC=0+-100 24546 C4-1/8-T0-1002-F
A5R32 0757-0438 15 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-T0-5111-P
A5R33 0698-0085 RESISTOR 2.61K 1% 125W F TC=0+-100 16299 C4-1I8-T0-2611-F
A5R34 0698-0085 RESISTOR 2.61K 1% .125W F TC=0+-100 16299 C4-1/8-T0-2611-F
A5R35 0757-0399 7 RESISTOR 82.5 1% .125W F TC=0+-100 24546 C4-1/8-T0-82R5-F
A5R36 0757-0399 RESISTOR 82.5 1% .125W F TC=0+-100 24546 C4-1/8-T0-8285-F
A5R37 0698-3391 1 RESISTOR 21.5 1% .5W F TC=0+-100 GM005 CEC, T-0
A5R38 0757-0198 1 RESISTOR 100 1% .5W F TC=0+-100 19701 MF7C1/2-T0-101-F
A5R39 0698-5839 2 RESISTOR 9.1 5% .25W FC TC=-400/+500 01121 CB91G5
A5R40 0698-5839 RESISTOR 9.1 5% .25W FC TC=-400/+500 01121 CB91G5
See introduction to this section for ordering information
† SEE TABLES 7-1 AND 7-2, FOR BACKDATING.
6-9
