TM 9-4935-601-14-7&P
Model 8640B
Table 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
A5R41 0698-3260 2 RESISTOR 464K 1% .125W F TC=0+-100 03888 PHE555
A5TP1 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28680 0360-1514
A5TP2 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A5TP3 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A5TP4 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A5TP5 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A5TP6 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A5U1 1820-0158 IC LM 302 CP ANP 27014 LM302H
A6 08640-60033 1 ANNUNCIATCR ASSY 28480 08640-60033
A6DS1 2140-0427 6 LAMP-INCAND 5VDC 60MA T-1-BULB 28480 2140-0427
A6DS2 2140-0427 LAMP-INCAND 5VDC 60MA T-1-BULB 28480 2140-0427
A6DS3 2140-0427 LAMP-INCAND 5VDC 60MA T-1-BULB 28480 2140-0427
A6DS4 2140-0427 LAMP-INCAND 5VDC 60MA T-1-BULB 28480 2140-042T
A6DS5 2140-0427 LAMP-INCAND 5VDC 60MA T-1-BULB 28480 2140-0427
A6DS6 2140-0427 LAMP-INCAND 5VDC 60MA T-1-BULB 28480 2140-0427
A6P1 1251-3054 1 CONNECTOR STRIP:9 OPEN POSITION 74868 221-68
1251-1249 1 PLZG KEY-PRINTED CIRCUIT CONN 9D949 143-953
1251-1313 1 CONTACT-CONN FEN CRP 9D949 220-502
A6R1 0757-0346 RESISTCR 10 1% .125W F TC=0+-100 24546 C4-1/8-T0-10R0-F
47† 08640-60046 1 FP SHAPING BOARD ASSY 28480 08640-60046
A7C1 0180-1735 3 CAPACITOR-FXD .22UF+-10% 35VDC TA 56289 150D224X9035A2
A7C2 0180-1735 CAPACITOR-FXD .22UF+-10% 35VDC TA 56289 150D224X9035A2
A7C3 0180-0373 1 CAPACITOR-FXD .68UF+-10% 35VDC TA 56289 150D684X9035A2
A7C4 0180-2141 1 CAPACITOR-FXD 3.3UF+-10% 50VDC TA 56289 150D335X9050B2
A7C5 0180-0141 2 CAPACITOR-FXD 50UF+75-10% 50VDC AL 56289 300506C050DD2
A7C6 0180-1715 CAPACITOR-FXD 150UF+-10% 6VDC TA 56289 150D157X9006R2
A7C7 0160-2453 1 CAPACITOR-FXD .22UF .-10% 80WVDC POLYE 28480 0160-2453
A7C8 0180-1846 1 CAPACITOR-FXD 2.2UF+-10% 35VDC TA 56289 1500225X9035B2
A7C9 0160-2204 CAPACITOR-FXD 100PF +-5% 300WVDC MICA 93790 RDM15F101J3C
A7C10 0180-0141 CAPACITOR-FXD 50UF+75-10% 50VDC AL 56289 30050650500DD2
A7C11 0180-1715 CAPACITOR-FXD 150UF+-10% 6VDC TA 56289 1500157X9006R2
A7C12 0160-2204 CAPACITOR-FXD 100PF+-5% 300WVDC MICA 93790 RDM15F101J3C
A7C13 0180-2206 1 CAPACITOR-FXD 60UF+-10% 6VDC TA 56289 1500606X9006B2
A1CR1 1901-0033 20 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
A7CR2 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
A7CR3 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
A7CR4 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
A7CR5 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
A7CR6 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
A7CR7 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
A7CR8 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
A7CR9 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
A7CR10 1901-0025 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0025
A7CR11 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
A7CR12 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
A7CR13 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
A7CR14 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
A7CR15 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
A7CR16 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
A7CR17 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
A7CR18 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
A7CR19 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
47CR20 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
47CR21 1901-0033 DIODE-GEN PRP 180V 200MA DO-7 28480 1901-0033
A7J1† 1250-0835 1 CONNECTOR-RF SMC M PC 24931 37JR104-2
A7K1 0490-1080 1 RELAY-REED 1C .25A 150V CONT 5V-COIL 28480 0490-1080
A7MP1 4040-0751 1 EXTRACTOR-PC BD ORN POLYC .062-B-THKNS 28480 4040-0751
1480-0073 PIN:DRIVE 0.250" LG 00000 OBD
A7MP2 4040-0748 1 EXTRACTOR-PC BD BLK POLYC .062-B-THKNS 28480 4040-0748
1480-0073 PIN:DRIVE 0.250" LG 00000 OBD
A7Q1 1854-0071 TRANSISTOR NPN SI PD=300MW FT-200MHZ 28480 1854-0071
A7Q2 1854-0071 TRANSISTOR NPN SI PD=300MW FT-200MHZ 28480 1854-0071
A7Q3† 1854-0022 TRANSISTOR NPN SI TO-39 PD-700MW 07263 S17843
1200-0173 INSULATOR-XSTR TO-5 .075-THR 28480 1200-0173
47Q4 1853-0020 9 TRANSISTOR PNP SI PD-300MW FT-150MHZ 28480 1853-0020
See introduction to this section for ordering information
† SEE TABLES 7-1 AND 7-2, FOR BACKDATING.
6-10
