Model 8640B TM 9-4935-601-14-7&P
Table 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
A7Q5 1854-0071 TRANSISTOR NPN SI PD=300MW FT=200MLHZ 28480 1854-0071
A7Q6† 1853-0038 TRANSISTOR PNP SI TO-39 PD-1W FT=100MHZ 28480 1853-0038
1200-0173 INSULATOR-XSTR TO-5.075-THK 28480 1200-0173
A7Q7 1853-0020 TRANSISTOR PNP SI PD=300MW FT=150MHZ 28480 1853-0020
A7Q8 1853-0020 TRANSISTOR PNP SI PD=300MW FT=1500MHZ 28480 1853-0020
A7R1 0698-3162 RESISTOR 46.4K 1% .125W F TC=0+-100 16299 C4-1/8-T0-4642-F
A7R2 0698-3450 3 RESISTOR 42.2K 1% 125W F TC=0+-100 16299 C4-1/8-T0-4222-F
A7R3 0698-3153 1 RESISTOR 3.83K 1% .125W F TC=0+-100 16299 C4-1/8-T0-3831-F
A7R4 0757-0199 RESISTOR 21.5K 1% .125W F TC=0+-100 24546 C4-1/8-T0-2152-F
A7R5 0757-0440 RESISTOR 7.5K 1% .125W F TC=0+-100 24546 C4-1/8-T0-7501-F
A7R6 0698 3243 1 RESISTOR 178K 1% .125W F TC=0+-100 16299 C4-1/8-T0-1783-F
A7R7 0698-3454 1 RESISTOR 215K 1% .125W F TC=0+-100 16299 C4-1/8-T0-2153-F
A7R8 0757-0289 1 RESISTOR 13.3K 1% .125W P TC=0+-100 19701 MF4C1/8-T0-1332-F
A7R9 0698-3161 1 RESISTOR 38.3K 1% .125W F TC=0+-100 16299 C4-1/8-T0-3832-F
A7R10 0698-3154 1 RESISTOR 4.22K 1% .125W F TC=0+-100 16299 C4-1/8-T0-4221-F
A7R11 0757-0288 RESISTOR 9.09K 1% .125W F TC=0+-100 19701 MF4C1/8-T0-9091-F
A7R12 2100-3109 RESISTOR-TRMR 2K 10% C SIDE=ADJ 17=TURN 32997 3006P-I-202
A7R13 0757-0279 RESISTOR 3.16K 1% .125W F TC=0+-100 24546 C41/8-T0-3161-F
A7R14 0698-3260 RESISTOR 4.64K 1%.125W F TC=0+-100 03888 PME55S
A7R15 0757-0458 2 RESISTOR 51.1K 1% .125W F TC=0+-100 24546 C4-1/8-T0-5112-F
A7R16 0757-0443 RESISTOR 11K 1% .125W F TC=0+-100 24546 C4-1/8-T0-1102-F
A7R17 0698-3155 3 RESISTOR 4.64K 1% .125W F TC=0+-100 16299 C4-1/8-T0-4641-F
A7R18 0757-0123 2 RESISTOR 34.5K 1% .125W F TC=0+-100 24546 C5-1/4-T0-3482-F
A7R19 2100-3103 1 RESISTOR-TRMR 10K 10% C SIDE-ADJ 17=TURN 32997 3006P-1-103
A7R20 0698-3152 1 RESISTOR 3.48K 1% .125W F TC=0+-100 16299 C4-1/8-T0-3481-F
A7R21 0757-1094 4 RESISTOR 1.47K 1% .125W F TC=0+-100 24546 C4-1/8-T0-1471-F
A7R22 0757-0278 2 RESISTOR 1.78K 1% .125W F TC=0+-100 24546 C4-1/8-T0-1781-F
A7R23 0757-0279 RESISTOR 3.16K 1% .125W F TC=0+-100 24546 C4-1/8-T0-3161-F
47R24 0757-0290 RESISTOR 6.19K 1% .125W F TC=0+-100 19701 MF41C1/8-T0-6191-F
A7R25 0757-0443 RESISTOR 11K 1% .125W F TC=0+-100 24546 C4-1/8-T0-1102-F
A7R26 0698-3157 RESISTOR 19.K 1% .125W F TC=0+-100 16299 C4-1/8-T0-1962-F
A7R27 0698-3160 RESISTOR 31.6K 1% .125W F TC=0+-100 16299 C4-1/8 T0-3162-F
A7R28‡ 0757-0465 1 RESISTOR 100K 1% .125W F TC=0+-100 24546 C4-1/8-T0-1003-F
A7R29 0757-0401 RESISTOR 100 1% .125W F TC=0+-100 24546 C4-1/8-T0-101-F
A7R30 0757-0403 RESISTOR 121 1% .125W F TC=0+-100 24546 C4-1/8-T0-121R-F
A7R31 0757 0399 RESISTOR 82.5 1% .125W F TC=0+-100 24546 C4-1/8-T0-82R5-F
A7R32 0757-0395 1 RESISTOR 56.2 1% .125W F TC=0+-100 24546 C4-1/8-T0-56R2-F
A7R33 0698-3435 1 RESISTOR 38.3 1% .125W F TC=0+-100 16299 C4-I1/8-T0-38R3-F
A7R34 0698-3432 2 RESISTOR 26.1 1% .125W F TC=0+-100 03888 PME55-1/8-T0-26R1-F
A7R35 0757-0294 1 RESISTOR 17.8 1% .125W F TC=0+-100 19701 MF4C1/8-T0-17R8-F
A7R36 0698-3427 1 RESISTOR 13.3 1% .125W F TC=0+-100 03888 PME55-1/8-T0-13R3-F
A7R37 0757-0346 RESISTOR 10 1% .125W F TC=0+-100 24546 C4-1/8-T0-10R0-F
A7R38 0757-0401 RESISTOR 100 1% .125W F TC=0+-100 24546 C4-1/8-T0-101-F
A7R39 0757-0280 RESISTOR 1K 1% .125W F TC=0+-100 24546 C4-1/8-T0-1001-F
A7R40 0757-0200 2 RESISTOR 5.62K 1% .125W F TC=0+-100 24546 C4-1/8-T0-5621-F
A7R41 2100-3109 RESISTOR-TRMR 2K 10% C SIDE-ADJ 17-TURN 32997 3006P-1-202
A7R42 0757-0442 RESISTOR 10K 1% .125W F TC=0+-100 24546 C4-1/8-T0-1002-F
A7R43 0698-3155 RESISTOR 4.64K 1% .125W F TC=0+-100 16299 C4-1/8-T0-4641-F
A7R44 0757-0443 RESISTOR 11K 1% .125W F TC=0+-100 24546 C4-1/8-T0-102-F
A7R45‡ 0698-3159 1 RESISTOR 26.1K 1% .125W F TC=0+-100 16299 C4-1/8-T0-2612-F
A7R46 0757 0123 RESISTOR 34.8K 1% .125W F TC=0+-100 24546 C5-1/4-T0-3482-F
A7R47 0698-3449 RESISTOR 28.7K 1% .125W F TC=0+-100 16299 C4-1/8-T0-2872-F
A7R48 0757-0199 RESISTOR 21.5K 1% .125W F TC=0+-100 24546 C4-1/8-T0-2152-F
47R49 0698-3136 1 RESISTOR 17.8K 1% .125W F TC=0+-100 16299 C4-1/8-T0-1782-F
A7R50 0757-0442 RESISTOR 10K 1% .125W F TC=0+-100 24546 C4-1/8-T0-1002-F
A7R51 0757 0440 RESISTOR 7.5K 1% .125W F TC=0+-100 24546 C4-1/8-T0-7501-F
A7R52 0757-0200 RESISTOR 5.62K 1% .125W F TC=0+-100 24546 C4-1/8-T0-5621-F
A7R53 0698-3151 2 RESISTOR 2.87K 1% .125W F TC=0+-100 16299 C4-1/8-T0-2871-F
A7R54 0757-1094 RESISTOR 1.47K 1% .125W F TC=0+-100 24546 C4-1/8-T0-1471-F
A7R55 0757-0401 RESISTOR 100 1% .125W F TC=0+-100 24546 C4-1/8-T-101-F
A7R56 0698 3432 RESISTOR 26.1 1% .125W F TC=0+-100 03888 PME55-1/8-T0-26R1-F
A7R57 0698-3433 1 RESISTOR 28.7 1% .125W F TC=0+-100 03888 PME55-1/8-T0-2BR7-F
A7R58 0698-3434 1 RESISTOR 34.8 1% .125W F TC=0+-100 16299 C4-1/8-T0-34R8-F
A7R59 0757-0316 1 RESISTOR 42.2 1% .125 F TC=0+-100 24546 C4-1/8-T0-42R2-F
A7R60 0757-0394 7 RESISTOR 51.1 1% .125W F TC=0+-100 24546 C4-1/8-T0-51R1-F
A7R61 0757 0276 1 RESISTOR 61.9 1% .125W F TC=0+-100 24546 C4-1/8-T0-6192-F
A7R62 0757-0398 RESISTOR 75 1% .125W F TC=0+-100 24546 C4-1/8-T0-75R0-F
A7R63 0757-0400 3 RESISTOR 90.9 1% .125W F TC=0+-100 24546 C4-1/8-T0-90R9-F
A7R64 0757-0403 RESISTOR 121 1% .125W F TC=0+-100 24546 C4-1/8-T0-121R-F
A7R65 0757-0405 1 RESISTOR 162 1% .125W F TC=0+-100 24546 C4-1/8-T0-162R-F
A7R66 0757 0401 RESISTOR 100 1% .125w F TC=0+-100 24546 C4-1/8-T0-101-F
A7R67-
A7R69 NOT ASSIGNED
A7R70 0698-3150 2 RESISTOR 2.37K 1% .125W F TC=0+-100 16299 C4-1/8-T0-2371-F
47R71 0757-0424 1 RESISTOR 1.1K 1% .125W F TC=0+-100 24546 C4-1/8-T0-1101-F
See introduction to this section for ordering information
† SEE TABLES 7-1 AND 7-2, FOR BACKDATING. ‡ SEE NOTE, CHANGE 34, SECTION 7.
6-11
