Model 8640B TM 9-4935-601-14-7&P
Table 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
A7R72 0698-3450 RESISTOR 42.2K 1% 25W F TC=0+-100 16299 C4-1/8-T0-4222-F
A7R73 0698-3450 RESISTOR 42.2K 1% .125W F TC=0+-100 16299 C4-1/8-T0-4222-F
A7R74 0698-3150 RESISTOR 2.37K 1% 125W F TC=0+-100 16299 C4-1/8-T0-2371-F
A7R75 0757-0420 RESISTOR 750 1% 125W F TC=0+-100 24546 C4-1/8-T0-751-F
ATR76 0757-0441 RESISTOR 8.2SK 1% .125W F TC=0+-100 24546 C4-1/8-T0-8251-F
A7R77 0757-0438 RESISTOR 5.11K 1% 125W F TC=0+-100 24546 C4-1/8-T0-5111-F
A7R78 0757-0346 RESISTOR 10 1% 125W F TC=0+-100 24546 C4-1/8-T0-10R0-F
A7R79 0757-0416 RESISTOR 511 1% .125W F TC-0-100 24546 C4-L/8-T0-511R-F
A7TP2 0360-1514 TERMINAL-STUD SGL-PIN PRESS-NTG 28480 0360-1514
A7TP2 0360-1514 TERHINAL-STUD SGL-PIN PRESS-IMTG 28480 0360-1514
A7TP3 0360-1514 TERMINAL-STUC SGL-PIN PRESS-MTG 28480 0360-1514
A7TP4 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A7U1 1826-0013 2 IC OP AMP 20480 1826-0013
A7U2 1820-0125 1 IC UA 711C COMPARATOR 07263 711HC
ATU3 1821-0175 1 IC SN74 05 N INV 01295 SNT405N
A7VR1 1902-0049 1 DIODE-ZNR 6.19V 5% DO-7 PD=.4W TC=+.022% 04713 SZ 10939-122
A7VR2 1902-3182 2 DIOOE-ZNR 12.1V 5% DO-7 PD=.4W TC=+.064% 04713 SZ 10939-206
A8 08640-60115 1 COUNTER/LOCK ASSY 28480 08640-60115
A8C1 0160-2049 4 CAPACITOR-FXD 5000PF +80-20% 500WVDC CER 28480 0160-2049
A8C2 0160-2049 CAPACITOR-FXD 5000PF +80-20% 500WVDC CER 28480 0160-2049
A8C3 0160-2049 CAPACITOR-FXD 5000PF +80-20% 500WVDC CER 26480 0160-2049
A8C4 0160-2049 CAPACITOR-FXD 5000PF +80-20% 500WVDC CER 28480 0160-2049
A8C5 0160-2357 2 CAPACITOR-FXD 1000PF +80-20% 500WVDC CER 28480 0160-2357
A8C6 0160-2357 CAPACITOR-FXD 1000PF +80-20% 500WVDC CER 28480 0160-2357
A8FL1 0160-0204 CAPACITOR-FLTR 5500PF GMV 200V 01121 SMFB-A2
A8FL2 0160-0204 CAPACITOR-FLTR 5500PF GMV 200V 01121 SMFB-A2
A8FL3 0160-0204 CAPACITOR-FLTR 5500PF GMV 200V 01121 SMFB-A2
A8FL4 0160-0204 CAPACITOR-FLTR 5500PF GNV 200V 01121 SMFB-A2
A8L1† 9100-2232 5 COIL-FXD MOLDED RF CHOKE .56UH 10% 24226 15/560
A8L2 † 9100-2232 COIL-FXD MOLDED RF CHOKE .56UH 10% 24226 15/560
A8L3 † 9100-2232 COIL-FXD MOLDED RF CHOKE .56UH 10% 24226 15/560
A8L4 9100-2232 COIL-FXD MOLDED RF CHOKE .56UH 10% 24226 15/560
A8L5 9100-2232 COIL-FXD MOLDED RF CHOKE .56UH 10% 24226 15/560
A8MP1 1200-0081 1 INSULATOR-BSHG-FLG .115-ID 26365 974 307
A8MP2 2190-0027 1 WASHER-LK INTL T NO.-1/4 .256-IN-ID 78189 1914-00
A8MP3 3050-0443 1 WASHER-FL NM NO.-8 .176-IN-ID. .375-1N-OD 86928 5624-16-10
A8MP4 8160-0219 1 RFI STRIP NI ALY 1.06-W 2.64-L 28400 8160-0219
A8MP5 8160-0220 1 RFI STRIP NI ALY 2.48-W 4.215-L 28480 8160-0220
A8MP6 08640-00001 1 SHIELD, LED TAPE 28480 00640-00001
A8MP7 08640-00009 1 COVER, CENTER FILTER 28480 08640-00009
A8MP8 08640-00051 1 FRAME C SHIELD, LARGE 28480 06640-00051
A8MP9 08640-00052 1 FRAME C SHIELD, SMALL 28480 08640-00052
A8MP10 08640-20280 1 COVER, CONTROL INPUT 28480 06640-20280
A8MP11 08640-20201 1 HEAT SINK 28480 08640-20281
A8MP12 08640-20063 1 WINDOW COUNTER 28480 08640-20063
A8MP13 08640-20089 1 SUPPORT, PC BOARD, CENTER 28480 08641-20069
A8MP14 00640-20092 1 SHIELD, BUTTON 28480 08640-20092
A8MP15 08640-20202 1 CASTING, TOP 28480 08640-20202
A8MP16 08640-20203 1 CASTING, BOTTOM 28480 08640-20203
A8MP17 08640-40003 1 PIPE LIGHT 28480 08640-40003
A8MP18 08640-40041 1 PIPE LIGHT, OVER-FLOW 28480 08640-40041
A8MP19 5040-0391 1 BUTTON:X10 25480 5040-0391
A8MP20 5040-0392 1 BUTTON:X100 28480 5040-0392
A8MP21 5040-0393 1 BUTTON-ON 28480 5040-0393
A8NP22 5040-0394 1 BUTTON-INT 28480 5040-0394
A8MP23 5040-0395 1 BUTTON-EXT 28480 5040-0395
A8MP24 2190-0368 1 WASHER-FL MITLC NO.-5 .13-IN-ID 28480 2190-0368
A8MP25 2190-0019 WASHER-LK HLCL NO.-4 .115-IN-ID 28480 2190-0019
A8MP26 2200-0147 2 SCREW-MACH 4-40 .5-IN-LG PAN-HD-POZI 28480 2200-0147
A8MP27 2200-0107 1 SCREW-MACH 4-40 .375-IN-LG PAN-HD-POZI 28480 2200-0107
A8MP28 2200-0151 1 SCREW-MACH 4-40 .75-IN-LG PAN-HD-POZI 28480 2200-0151
A8MP29 2190-0005 1 WASHER-LK EXT T NO.-4 .116-IN-ID 78189 1804-01
A8MP30 2950-0006 1 NUT-HEX-DBL-CHAM 1/4-32-THD .094-TNK 73734 9000
A8MP31 2200-0140 1 SCREW-MACH 4-40 .25-IN-LG 100 DEC 28480 2200-0140
A8MP32 08640-00058 1 INSULATOR, COUNTER 28480 08640-00058
A8MP33 2200-0105 SCREW-MACH 4-40 .312-IN-LG PAN-HD-POZI 28480 2200-0105
A8MP34 0520-0127 1 SCREW-MACH 2-56 .188-IN-LG PAN-HD-POZI 28480 0520-0127
A8MP35 2190-0014 1 WASHER-LK INTL T NO.-2 .089-IN-ID 78189 1902-00
A8MP36 0516-0005 1 SCREW-MACH 0-80 .188-IN- LG PAN-HD-SLT 28480 0516-0005
A8MP37 2200-0103 1 SCREW-MACH 4-40 .25-IN-LG PAN-HD-POZI 28480 2200-0103
A8MP38 2200-0155 2 SCREW-MACH 4-40 1-IN-LG PAN-HD-POZI 28480 2200-0155
A8MP39 0361-0207 1 RIVET:BLIND. BLACK NYLON 0.125" DIA 00000 OBD
A8MP40 2200-0504 1 SCREW-MACH 4-40 1.062-IN-LG PAN-HD 28480 2200-0504
See introduction to this section for ordering information
† SEE TABLES 7-1 AND 7-2, FOR BACKDATING.
6-12
