Model 8640B TM 9-4935-601-14-7&P
Table 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
A8A2C16 0160-3879 CAPACITOR-FXD .01UF +-20% 100WVDC CER 28480 0160-3879
A8A2C17 0160-0174 4 CAPACITOR-FXD .47UF +- 80-20% 25WVDC CER 28480 0160-0174
A8A2C18 0160-3094 CAPACITOR-FXD .1UF +- 10% 100WVDC CER 28480 0160-3094
A8A2C19† 0160-2201 4 CAPACITOR-FXD 51PF +- 5% 300WVDC MICA 28480 0160-2201
A8A2C20 0180-0291 1 CAPACITOR-FXD 1UF +-10% 35VDC TA 56289 150D105X9035A2
A8A2C21 0180-0197 CAPACITOR-FXD 2.2UF+-10% 20VDC TA 56289 150D225X9020A2
A8A2C22 0160-3879 CAPACITOR-FXD .01UF + 2% 100WVDC CER 28480 0160-3879
A8A2C23 0180-0197 CAPACITOR-FXD 2.2UF10% 20VDC TA 56289 150D225X9020A2
A8A2C24 0160-2055 CAPACITOR-FXD .01UF +80-20% 10WVDC CER 28480 0160-2055
A8A2C25 0160-2055 CAPACITOR-FXD .01UF +80-20% 100WVDC CER 28480 0160-2055
A8A2C26 0160-2055 CAPACITOR-FXD .01UF +80%20% 100WVDC CER 28480 0160 2055
A8A2C27† 0160-2204 5 CAPACITOR-FXD 100PF +-5%300WVDC MICA 93790 RDM1SF101J3C
A8A2C28 † 0160-3876 4 CAPACITOR-FXD 47PF +-20% 200WVDC CER 28480 0160- 3876
A8A2C29 † 0160-3876 CAPACITOR-FXD 47PF +-20% 200WVDC CER 28480 0160-3876
A8A2C30 † 0160-3876 CAPACITOR-FXD 47PF+ -20% 200WVDC CER 28480 0160-3876
A8A2CR1 1901-0040 DIODE-SWITCHING 30V 50MA 2NS D0-35 28480 1901-0040
A8A2CR2 1901-0040 DIODE-SWITCHING 30V 50MA 2NS D0-35 28480 1901-0040
A8A2J1 1200-0448 1 SOCKET-IC 1-CONT DIP-SLDR-TERMS 27264 1938-4G1
A8A2L1† 9100 1622 1 COIL-FXD MOLDED RF CHOKE 24UH 5% 24226 15/242
A8A2L2 † 9100-1620 6 COIL-FXD MOLDED RF CHOKE 15UH 10 24226 15/152
A8A2Q1 1854-0071 TRANSISTOR NPN SI PD=300MW FT=200MHZ 28480 1854-0071
A8A2Q2 1853-0020 TRANSISTOR PNP SI PD=300MW FT=150MHZ 28480 1853-0020
A8A2Q3 1853-0020 TRANSISTOR PNP SI PD=300MW FT=150MFZ 28480 1853-0020
A8A2Q4 1854-0071 TRANSISTOR NPN SI PD=300MW FT=200MHZ 28480 1854-0071
A8A2A5 1854-0071 TRANSISTOR NPN SI PD=300MW FT=200MHZ 28480 1854-0071
A8A2Q6 1855-0062 1 TRANSISTOR J-FET N-CHAN D-MODE SI 28480 1855-0062
A8A2Q7 1853 0020 TRANSISTOR PNP SI PD=300MW FT=150MHZ 28480 1853-0020
A8A2Q8 1854-0071 TRANSISTCR NPN SI PD=300MW FT=200MHZ 28480 1854-0071
A8A2Q9 1854-0071 TRANSISTOR NPN SI PD=300MW FT=200MHZ 28480 1854-0071
A8A2Q10 1854-0071 TRANSISTOR NPN SI PD=300MW FT=200MHZ 28480 1854-0071
A8A2Q11 1854-0071 TRANSISTOR NPN SI PD=300MW FT=200MHZ 28480 1854-0071
A8A2Q12 1854 0071 TRANSISTOR NPN SI PD=300MW FT=200MHZ 28480 1854-0071
A8A2Q13 1853-0020 TRANSISTOR PNP SI PD=300MW FT=150MHZ 28480 1853-0020
A8A2Q14 1854-0071 TRANSISTOR NPN SI PD=300MW FT=200MHZ 284e0 1854-0071
A8A2Q15 1854-0071 TRANSISTOR NPN SI PD=300MW FT=200MHZ 28480 1854-0071
A8A2Q16 1853-0020 TRANSISTOR PNP SI PD=300MW FT=150MHZ 28480 1853-0020
A8A2Q17 1853-0020 TRANSISTOR PNP SI PD=300MW FT=150MHZ 28480 1853-0020
A8A2Q18 1854-0071 TRANSISTOR NPN SI PD=300MW FT=200MHZ 28480 1854-0071
A8A2R1 0698-3440 RESISTOR 196 1% .125W F TC=0+-100 16299 C4-1/8 TO-1962-F
A8A2R2 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A8A2R3 0698-7253 6 RESISTOR 5.11K 2% .05W F TC=0+-100 24546 C3-1/8-TO-5111-G
A8A2R4 0698-7253 RESISTOR 5.11K 2% .05W F TC=0+-100 24546 C3-1/8-TO-5111-G
A8A2R5 0698-7239 2 RESISTOR 1.33K 2% .05W F TC=0+ 100 24546 C3-1/8-TO-1331-G
A8A2R6 0698-7239 RESISTOR 1.33K 2% .05W F TC=0+-100 24546 C3-1/8-TO-1331-G
A8A2R7 0698-7246 2 RESISTOR 2.61K 2% .05W F TC=0+-100 24546 C3-1/8-TO-2611-G
A8A2R8 0698-7246 RESISTOR 2.61K 2% .05W F TC=0+-100 24546 C3-1/8-TO-2611-G
A8A2R9 0698-7277 RESISTOR 51.1K 2% .05W F TC=0+-100 24546 C3-1/8-TO-5112-G
A8A2R10 0698-7277 RESISTOR 51.1K 2% 05W F TC=0+-100 24546 C3-1/8-TO-5112-G
A8A2R11 0683-8245 2 RESISTOR 820K 5% .25W FC TC=-800/+900 01121 C88245
A8A2R12 0683-8245 RESISTOR 820K 5% .25W FC TC=-800/+900 01121 C88245
A8A2R13 0698-7267 2 RESISTOR 19.6K 2% .05W F TC=0+-100 24546 C3-1/8-TO-1962-G
A8A2R14 0698-7272 1 RESISTOR 31.6K 2% 05W F TC=0+-100 24546 C3-1/8-TO-3162-G
A8A2R15 0698-7277 RESISTOR 51.1K 2% .05W F TC=0+-100 24546 C3-1/8-TO-5112-G
A8A2R16 0698-7267 RESISTOR 19.6K 2% .05W F TC=0+-100 24546 C3-1/8-TO-1962-G
A8A2R17 0698-7284 3 RESISTOR 100K 2% .05W F TC=0+-100 24546 C3-1/8-TO-0033-G
A8A2R18 0698-7284 RESISTOR 100K 2% 05W F TC=0+-100 24546 C3-1/8-TO-1003-G
A8A2R19 0698-7277 RESISTOR 51.1K 2% .05W F TC=0+-100 24546 C3-1/8-TO-5112-G
A8A2R20 0698-7288 1 RESISTOR 147K 2% .05W F TC=0+-100 24546 C3-1/8-TO-1473-G
A8A2R21 0698-7253 RESISTOR 5.11K 2% .05W F TC=0+-100 24546 C3-1/8-TO-5111-G
A8A2R22 0698-7253 RESISTOR 5.11K 2% .05W F TC=0+-100 24546 C3-1/8-TO-5111-G
A8A2R23 0698-7277 RESISTOR 51.1K 2% .05W F TC=0+-100 24546 C3-1/8-TO-5112-G
A8A2R24 0698-7260 5 RESISTOR 10K 2% .05W F TC=0+-100 24546 C3-1/8-TO-1002-G
A8A2R25 0698-7284 RESISTOR 100K 2% .05W F TC=0+-100 24546 C3-1/8-TO-1003G
A8A2R26 0698-3453 1 RESISTOR 196K 1% .125W F TC=0+-100 16299 C3-1/8-TO-1963-F
A8A2R27
0698-7260 RESISTOR 10K 2% .05W F TC=0+-100 24546 C3-1/8-TO-1002-G
A8A2R28 0698-7260 RESISTOR 10K 2% .05W F TC=0+-100 24546 C3-1/8-TO-1002-G
A8A2R29 0698-7256 1 RESISTOR 6.81K 2% .05W F TC=0+-100 24546 C3-1/8-TO-6811-G
A8A2R30 0698-7258 1 RESISTOR 8.25K 2% .05W F TC=0+-100 24546 C3-1/8-TO-8251-G
A8A2R31 0698-7260 RESISTOR 10K 2% .05W F TC=0+-100 24546 C3-1/8-TO-1002-G
A8A2R32 0698-7260 RESISTOR 10K 2% .05W F TC=0+-100 24546 C3-1/8-TO-1002-G
A8A2R33 0698-7264 1 RESISTOR 14.7K 2% .05W F TC=0+-100 24546 C3-1/8-TO-1472-G
A8A2R34 0698-7243 1 RESISTOR 1.96K 2% .05W F TC=0+-100 24546 C3-1/8-TO-1961-G
A8A2R35 0698-7229 5 RESISTOR 511 2% .05W F TC=0+-100 24546 C3-1/8-TO-511R-G
See introduction for ordering information
†SEE TABLES 7-1 AND 7-2, FOR BACKDATING.
6-14
