Model 8640B TM 9-4935-601-14-7&P
Table 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
A8A2R36 0757-0442 RESISTOR 10K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A8A2R37 0757-0416 RESISTOR 511 1% .125W F TC=0+-100 24546 C4-1/8-TO-511R-F
A8A2R38 0698-3442 1 RESISTOR 237 1% .125W F TC=0+-100 16299 C4-1/8-TO-237R-F
A8A2R39 0757-0442 RESISTOR 10K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A8A2R40 0757-0279 RESISTOR 3.16K 1% .125W F TC=0+-100 24546 C4-1/8-TO-3161-F
A8A2R41 0757-0442 RESISTOR 10K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A8A2R42 0698-0083 5 RESISTOR 1.96K 1% 125W F TC=0+-I00 16299 C4-1/8-TO-1961-F
A8A2R43 0698-0083 RESISTOR 1.96K 1% .125W F TC=0+-100 16299 C4-1/8-TO-1961-F
A8A2R44 0698-0083 RESISTOR 1.96K 1% .125W F TC=0+100 16299 C4-1/8-TO-1961-F
A8A2R45 0757-0416 RESISTOR 511 1% .125W F TC=0+-100 24546 C4-1/8-TO-511R-F
A8A2R46 NOT ASSIGNED
A8A2R47 0757-0416 RESISTOR 511 1% .125W F TC=0+-100 24546 C4-1/8-TO-511R-F
A8A2R48 NOT ASSIGNED
A8A2R49 0698 7229 RESISTOR 511 2% 05W F TC=0+-100 24546 C3-1/8-TO-511R-G
A8A2R50 0757-0280 RESISTOR 1K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1001-F
A8A2R51 0698-7248 RESISTOR 3.16K 2% .05W F TC=0+-100 24546 C3-1/8-TO-3161-G
A8A2R52 0698-7248 RESISTOR 3.16K 2% 05W F TC=0+100 24546 C3-1/8-TO-31611G
A8A2R53 0698-7229 RESISTOR 511 2% .05W F TC=0+-100 24546 C3-1/8-TO-511R-G
A8A2R54 0698-7229 RESISTOR 511 2%.05W F TC=0+-100 24546 C3-1/8-TO-511R-G
A8A2R55 0698-7236 RESISTOR 1K 2% .05W F TC=0+-100 24546 C3-1/8 TO-1001-G
A8A2R56 0811-1662 1 RESISTOR .47 5% 2W PW TC=0+-800 75042 BWH2-47/100-J
A8A2R57 0698-7219 3 RESISTOR 196 2% .05W F TC=0+-100 24546 C3-1/8-TO-196R-G
A8A2S1A 3101-1729 1 SWITCH-P8 15MM C-C SPACING 28480 3101-1729
A8A2S1B NSR P/O A8A2S1A
A8A2S1C NSR P/O A8A2S1A
A8A2P1 0360 1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A8A2P2 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A8A2P3 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A8A2P4 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A8A2P5 0360-1514 TFRMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A8A2P6 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A8A2U1 1820-0077 4 IC SN74 74 N FLIP-FLOP 01295 SN7474N
A8A2U2 1820-0054 IC SN74 00 N GATE 01295 SN7400N
A8A2U3 1820-0054 IC SN74 00 N GATE 01295 SN7400N
A8A2U4 1820-0174 2 IC SN74 04 N INV 01295 SN7404N
A8A2U5 1820-0077 IC SN74 74 N FLIP-FLOP 01295 SN7474N
A8A2U6 1820-0328 2 IC SN74 02 N GATE 01295 SN7402N
A8A2U7 1820-0701 6 IC LATCH 07263 93L14DC
A8A2U8 1820-0701 IC LATCH 07263 93L14DC
A8A2U9 1820-0701 IC LATCH 07263 93L14DC
A8A2U10 1820-0701 IC LATCH 07263 93L14DC
A8A2U11 1820-0701 IC LATCH 07263 93L14DC
A8A2U12 1820-0701 IC LATCH 07263 93L14DC
A8A2U13 1820-0511 IC SN74 08 N GATE 01295 SN7408N
A8A2U14 1820-0205 2 IC MC 3003P GATE 04713 MC3003P
A8A2U15 1820-0054 IC SNT4 00 N GATE 01295 SN7400N
A8A2U16 1820-0054 IC SN74 00 N GATE 01295 SN7400N
A8A2U17 1820-0511 IC SN74 08 N GATE 01295 SN7408N
A8A2U18 1820-0511 IC SN74 08 N GATE 01295 SN7408N
A8A2U19 1820-0546 7 IC SN74 192 N COUNTER 01295 SN74192N
A8A2U20 1820-0546 IC SN74 192 N COUNTER 01295 SN74192N
A8A2U21 1820-0546 IC SN74 192 N COUNTER 01295 SN74192N
A8A2U22 1820-0546 IC SN74 192 N COUNTER 01295 SN74192N
A8A2U23 1820-0546 IC SN74 192 N COUNTER 01295 SN74192N
A8A2U24 1820-0546 IC SN74 192 N COUNTER 01295 SN74192N
A8A2U25 1820-0328 IC SN74 02 N GATE 01295 SN7402N
A8A2U26 1820-0077 IC SN74 74 N FLIP-FLOP 01295 SN7474N
A8A2U27 1820-0205 IC MC 3003P GATE 04713 MC3003P
A8A2U28 1820-0546 IC SN74 192 N COUNTER 01295 SN74192N
A8A2U29 1826-0092 1 IC MC 1458 OP AMP 28480 1826-0092
A8A2VR1 1902-3070 1 DIODE-ZNR 4.22V 5 D0-7 PD=.4W TC=-.038% 04713 SZ 10939-74
A8A2VR2 1902-3182 DIODE-ZNR 12Z.V 52 D0-7 PD=.4W TC=+.064% 04713 SZ 10939-206
A8A3 08640-60026 1 TIME BASE ASSY 28480 08640-60026
A8A3C1 0160-3094 CAPACITOR-FXD .1UF +- 10% 100WVDC CER 28480 0160-3094
A8A3C2 0160-3094 CAPACITOR-FXD .1UF +- 10% 100WVDC CER 28480 0160-3094
A8A3C3 0160-3094 CAPACITOR-FXD .1UF +- 10% 100WVDC CER 28480 0160-3094
A8A3C4 0160-3094 CAPACITOR-FXD .1UF +- 10% 100WVDC CER 28480 0160-3094
A8A3C6 0160-3094 CAPACITOR-FXD .1UF +- 10% 100WVDC CER 28480 0160-3094
A8A3C7 0160-3094 CAPACITOR-FXD .1UF +- 10% 100WVDC CER 28480 0160-3094
NOT ASSIGNED
A8A3C8 0160-2055 CAPACITOR-FXD .01UF +80-20% 100WVDC CER 28480 0160-2055
A8A3C9 0160-2055 CAPACITOR-FXD .01UF +80-20% 100WVDC CER 28480 0160-2055
A8A3C10 0160-2055 CAPACITOR-FXD .01UF +80-20% 100WVDC CER 28480 0160-2055
See introduction for ordering information
†SEE TABLES 7-1 AND 7-2, FOR BACKDATING.
6-15
