Model 8640B TM 9-4935-601-14-7&P
Table 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
A8A3C11 0160-2055 CAPACITOR-FXD .01UF +80-20% 100WVDC CER 28480 0160-2055
A8A3C12 0160-2055 CAPACITOR-FXD .01UF +80-20% 100WVDC CER 28480 0160-2055
A8A3C13 0160-2055 CAPACITOR-FXD .01UF +80-20% 100WVDC CER 28480 0160-2055
A8A3C14 0160-3094 CAPACITOR-FXD .1UF+- 10% 100WVDC CER 28480 0160-3094
A8A3C15 0160-3879 CAPACITOR-FXD .01UF +-20% 100WVDC CER 28480 0160-3879
A8A3C16 0160-2055 CAPACITOR-FXD .01UF +80-20% 10WVDC CER 28480 0160-2055
A8A3C17 0160-3094 CAPACITOR-FXD .1UF +-10% 100WVDC CER 28480 0160-3094
A8A3C18 0160-2055 CAPACITOR-FXD .01UF +80-20% 100HOWVDC CER 28480 0160-2055
A8A3C19 0160-3879 CAPACITOR-FXD .01UF +-20% 100WVDC CER 28480 0160-3879
A8A3C20 0160-3879 CAPACITOR-FXD .01UF +-20% 100VDC CER 28480 0160-3879
A8A3C21 0160-3877 CAPACITOR-FXD 10PF +-20% 2000WVDC CER 28480 0160-3877
A8A3C22 0160-3877 CAPACITOR-FXD 100PF +-20% 200VDC CER 28480 0160-3877
A8A3C23 0160-3457 1 CAPACITOR-FXD 2000PF +-10% 250WVDC CER 28480 0160-3457
A8A3C24 0160-3456 CAPACITOR-FXD 1000PF +- 01%100WVDC CER 28480 0160-3456
A8A3C25 0160-3094 CAPACITOR-FXD .1UF +-10% 100WVDC CER 28480 0160-3094
A8A3C26 0160-2055 CAPACITOR-FXD .01UF +-80-201 100VDC CER 28480 0160-2055
A8A3C27 0180-0197 CAPACITOR-FXD 2.2UF+-10 20VDC TA 56289 1500225X9020A2
A8A3C28 0180-0197 CAPACITOR-FXD 2.2UF+-10 20VDC TA 56289 1500225X9020A2
A8A3C29 0180-0197 CAPACITOR-FXD 2.2UF+-10 20VDC TA 56289 1500225X9020A2
A8A3C30 0180-0197 CAPACITOR-FXD 2.2UF+-10 20VDC TA 56289 1500225X9020A2
A8A3C31 0180-0197 CAPACITOR-FXD 2.2UF+-10 20VDC TA 56289 1500225X9020A2
A8A3C32 0160-3094 CAPACITOR-FXD .1UF+-100VDC CER 28480 0160-3094
A8A3C33 0160-2055 CAPACITOR-FXD .01UF +-80-20 100WVDC CER 28480 0160-2055
A8A3C34 0180-0197 CAPACITOR-FXD 2.2UF+-10% 20VDC TA 56289 1500225X9020A2
A8A3C35 0180-0197 CAPACITOR-FXD 2.2UF+-10% 20VDC TA 56289 1500225X9020A2
A8A3C36 0180-0197 CAPACITOR-FXD 2.2UF+- 10 20VDC TA 56289 1500225X9020A2
A8A3C37 0180-0197 CAPACITOR-FXD 2.2UF+- 101 20VDC TA 56289 1500225X9020A2
A8A3C38 0160-2055 CAPACITOR-FXD .01 UF +- 80-20% 100WVDC CER 28480 0160-2055
A8A3C39 0180-0197 CAPACITOR-FXD 2.2UF+-10% 20VDC TA 56289 1500225X9020A2
A8A3C40 0160-3456 CAPACITOR-FXD 1000PF +-10% 1000WVDC CER 28480 0160-3456
A8A3CR1 1901-0040 DIODE-SWITCHING 30V 50HA 2NS DO-35 28480 1901-0040
A8A3J1 1250-1383 1 CONNECTOR-REF SM SNP M SGL HOLE RR 28480 1250-1383
A8A3L1 9140-0137 10 COIL-FXD MOLDED RF CHOKE 1MH 5% 24226 19/104
A8A3L2 9140-0137 COIL-FXD MOLDED RF CHOKE 1MH 5% 24226 19/104
A8A3L3 9140-0137 COIL-FXD MOLDED RF CHOKE 1MH 5% 24226 19/104
A8A3L4 9140-0137 COIL-FXD MOLDED RF CHOKE 1MH 5% 24226 19/104
A8A3L5 9140-0137 COIL-FXD MOLDED RF CHOKE 1MH 5% 24226 19/104
A8A3L6 9140-0137 COIL-FXD MOLDED RF CHOKE 1MH 5% 24226 19/104
A8A3L7 9140-0137 COIL-FXD MOLDED RF CHOKE 1MH 5% 24226 19/104
A8A3L8 9140-0137 COIL-FXD MOLDED RF CHOKE 1MH 5% 24226 19/104
A8A3L9 9140-0137 COIL-FXD MOLDED RF CHOKE 1MH 5% 24226 19/104
A8A3L10 08640-80001 8 FILTER, TOROID 28480 08640-80001
A8A3L11 9140-0137 COIL-FXD MOLDED RF CHOKE 1MH 5% 24226 19/104
A8A3L12 08640-80001 FILTER, TOROID 28480 08640-80001
A8A3L13 08640-80001 FILTER, TOROID 28480 08640-80001
A8A3L14 08640-80001 FILTER, TOROID 28480 08640-80001
A8A3MP1 2190-0003 2 WASHER-LK HLCL NO.-4 .115-IN-IC 28480 2190-0003
A8A3MP2 2200-0155 SCREW-MACH 4-40 1-IN-LG PAN-HD-POZI 28480 2200-0155
A8A3MP3 2260-0001 1 NUT-HEX-OBL-CHAM 4-40-THD .094-THK 28480 2260-0001
A8A3MP4 08640-20211 1 GUIDE, CONNECTOR 28480 08640-20211
A8A3MP5 08640-40040 1 INSULATOR SWITCH 28480 08640-40040
A8A3Q1 1854-0019 TRANSISTOR NPN SI TO-18 PD=360MW 28480 1854-0019
A8A3Q2 1854-0019 TRANSISTOR NPN SI TO-18 PD=360MW 28480 1854-0019
A8A3R1 0698-3155 RESISTOR 4.64K 1% .125W F TC=0+-100 16299 C4-1/8-TO-4641-F
A8A3R2 0757-0274 2 RESISTOR 1.21K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1213-F
A8A3R3 0757-0442 RESISTOR 10K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A8A3R4 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A8A3R5 0698-7229 RESISTOR 511 2%.05H F TC=0+-100 24546 C3-1/8-TO-511R-G
A8A3R6 0757-0416 RESISTOR 511 1% .125W F TC=+-100 24546 C4-1/8-TO-511R-F
A8A3R7 0757-0442 RESISTOR 10K 1% 125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A8A3R8 0757-0442 RESISTOR 10K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A8A3R9 0698-0085 RESISTOR 2.61K 1% .125W F TC=0+-100 16299 C4-1/8-TO-2611-F
A8A3R10‡ 0698-0083 RESISTOR 1.96K 1% .125W F TC=0+-100 16299 C4-1/8-TO-1961-F
A8A3R11 0757-0416 RESISTOR 511 1% .125W F TC=0+-100 24546 C4-1/8-TO-511R-F
A8A3R12 0757-0416 RESISTOR 511 1% .125W F TC=+-100 24546 C4-1/8-TO-511R-F
A8A3R13 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A8A3R14 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A8A3R15 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A8A3R16 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A8A3R17 0698-0083 RESISTOR 1.96K 1% .125W F TC=0+-100 16299 C4-1/8-TO-1961-F
A8A3R18‡ 0757-0399 RESISTOR 82.5 1% .125W F TC=0+-100 24546 C4-1/8-TO-82R5-F
A8A3R19 0698-3437 3 RESISTOR 133 1%.125W F TC=0+-100 16299 C4-1/8-TO-133R-F
A8A3R20 0698-3160 RESISTOR 31.6K 1% .125W F TC=0+-100 16299 C4-1/8-TO-3162-F
See introduction for ordering information
‡ SEE NOTE, CHANGE 33, SECTION 7
6-16
