Model 8640B TM 9-4935-601-14-7&P
Table 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
A11 08640-60020 1 FIXED:-FREQUENCY MODULATION OSCILLATOR 28480 08640-60020
(STANDARD MODULE)
A11C1 0160-3548 1 CAPACITOR-FXD .01UF +-1% 100WVDC MICA 28480 0160-3548
A11C2 0160-0336 1 CAPACITOR-FXD 100PF +-1% 300WVDC MICA 28480 0160-0336
A11C3 0180-0094 2 CAPACITOR-FXD 100UF+75-10%: 25VDC AL 56289 30D107G025DD2
A11C4 0180-0094 CAPACITOR-FXD 100UF+75-10% 25VDC AL 56289 30D107G025D02
A11C5 0180-2206 1 CAPACITOR-FXD 60UF+-10 6VDC TA 56289 150D606X900682
A11C6 0180-1746 2 CAPACITOR-FXD 15UF+-10% 20VDC TA 56289 150D156X902082
A11C7 0180-1746 CAPACITOR-FXD 15UF+-10% 20VDC TA 56289 150D156X902082
A11CR1 1901-0040 3 DIODE-SWITCHING 30V 50MA 2NS D0-35 28480 1901-0040
A11CR2 1901-0040 DIODE-SWITCHING 30V 50MA 2NS D0-35 28480 1901-0040
A11CR3 1901-0040 DIODE-SWITCHING 30V 50MA 2NS D0-35 28480 1901-0040
A11Q1 1854-0003 4 TRANSISTOR NPN SI TO-39 PD=800MW 28480 1854-0003
1200-0173 4 INSULATOR-XSTR TO-5 .075-THK 28480 1200-0173
A11Q2 1854-0003 TRANSISTOR NPN SI TO-39 PD=800MW 28480 1854-0003
1200-0173 INSULATOR-XSTR TO-5 .075-THK 28480 1200-0173
A11Q3 1854-0071 2 TRANSISTOR NPN SI PD=300MW FT=200MHZ 28480 1854-0071
A11Q4 1854-0003 TRANSISTOR NPN SI TO-39 PD=800MHZ 28480 1854-0003
1200-0173 INSULATOR-XSTR TO-5 .075-THK 28480 1200-0173
A11Q5 1854-0003 TRANSISTOR NPN SI TO-39 PD=800MW 28480 1854-0003
1200-0173 INSULATOR-XSTR TO-5.075-THK 28480 1200-0173
A11Q6 1854-0071 TRANSISTOR NPN SI PD=300MW FT=200MHZ 28480 1854-0071
A11R1 NOT ASSIGNED
A11R2 0757-0346 1 RESISTOR 10 1% .125 F TC=0+-100 24546 C4-1/8-TO-10R0-F
A11R3 0757-0438 RESISTOR 5.11 1% .125W F TC =0+-100 24546 C4-1/8-TO-51L-F
A11R4 0698-3457 1 RESISTOR 316K 1% .125WF TC= 0+-100 03888 PME55S
A11R5 0698-0085 2 RESISTOR 2.61K 1% .125W F TC=0+-100 16299 C4-1/8-TO-2611-F
A11R6 2100-31758 1 RESISTOR-TRNR 1K 5% WW SIDE-ADJ 1-TURN GB027 CT-106-4
A11R7 0698-3151 1 RESISTOR 2.87K 1% .125 W F TC=0+-100 16299 C4-1/8-TO-2871-F
A11R8 0757-0280 2 RESISTOR 1K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1001-F
A11R9 0698-3453 1 RESISTOR 196K 1% .125W F TC =0+-100 16299 C4-1/8-TO-1963-F
A11R10 0757-0280 RESISTOR 1K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1001-F
A11R11‡ 0757-0438 4 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A11R12 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A11R13 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A11R14 0698-0085 RESISTOR 2.61K 1% .5W F TC=0+-100 51629 C4 1/8-TO-2611F
A11R15 0757-0401 RESISTOR 100 1% .125W F TC=0+-100 24546 C4-1/8-TO-101-F
A11R16 0757-0401 RESISTOR 100 1% .125W F TC=0+-100 24546 C4-1/8-TO-101-F
A11R17 0757-0401 RESISTOR 100 1% .125W F TC=0+-100 24546 C4-1/8-TO-101-F
A11R18 0757-0401 RESISTOR 100 1% .125W F TC=0+-100 24546 C4-1/8-TO-101-F
A11R19 0698-0024 4 RESISTOR 2.61K 1% .5W F TC=0+-100 24546 NA6
A11R20 0698-0024 RESISTOR 2.61K 1% .5W F TC=0+-100 24546 NA6
A11R21 0698-0024 RESISTOR 2.6K 1% .5% F TC=0+-100 24546 NA6
A11R22 0698-0024 RESISTOR 2.6K 1% .5% F TC=0+-100 24546 NA6
A11R23 0757-1100 RESISTOR 600 1% .125W F TC=0+-100 24546 C4-1/8-TO-601-F
A11R24 0757-1100 RESISTOR 600 1% .125W F TC=0+-100 24546 C4-1/8-TO-601-F
A11R25 0757-0442 RESISTOR 600 1% .125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A11R26 0757-0442 2 RESISTOR 10K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A11TP1 0360-1514 6 TREMINAL STUD SGL-PIN PRESS-MTG 28480 0360-1514
A11TP2 0360-1514 TERMINAL STUD SGL-PIN PRESS-MTG 28480 0360-1514
A11TP3 0360-1514 TERMINAL STUD SGL-PIN PRESS-MTG 28480 0360-1514
A11TP4 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A11TP5 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A11TP6 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A11U2 1826-0007 IC UA 741 0P AMP 28480 1826-0007
A11VR1 1902-0049 2 DIODE-ZNR 6.19V 5% D0-7 PD=.4w TC-+.022% 04713 SZ 10939-122
A11VR3 1902-0049 DIODE-ZNR 6.19V 5% D0-7 PD=.4W TC-+.022% 04713 SZ 10939-122
A11A1 08640-60116 1 FREQUENCY SELECT SWITCH ASSY 28480 08640-60116
A11A1MP1 08640-20218 1 HOUSING, GEAR SPROCKET, AUDIO 28480 08640-20218
A11A1R1 0698-8272 2 RESISTOR 157K 1t .125w F TC1=O+100 19701 MF4C1/8-TO-1573-F
A11A1R2 0757-0479 2 RESISTOR 392K 1I 125w F TC-O+-100 19701 MF4C1/8-TO-3923-F
A11A1R3 0698-8272 RESISTOR 157K t1 125W F TC-O+-100 19701 MF4C1/8-TO-1573-F
A11A1R4 0757-0479 RESISTOR 392K 1S .125W F TC=O+-100 19701 MF4C1/8-TO-3923-F
A11A1S1 3100-3091 1 SWITCH:ROTARY 28480 3100-3091
See introduction for ordering information
†SEE TABLES 7-1 AND 7-2, FOR BACKDATING.
6-24
