TM 9-4935-601-14-7&P
Model 8640B
Table 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
A11 08640-60019 1 VARIABLE-FREQUENCY MODULATION OSC. ASSY 28480 08640-60019
(OPTION 001)
A11C1 0121-0477 1 CAPACITOR-V A1R DIEL 10.3/365.7PF 350V 80486 2112 MODIFIED
(INCLUDES C2, C3)
A11C2 NSR PART OF A11C1
A11C3 NSR PART CF A11C1
A11C4 0160-2257 1 CAPACITOR-FXD 10PF +-5% 500WVDC CER 28480 0160-2257
A11C5 0160-2261 2 CAPACITOR-FXD 15PF +-5% 500WVDC CER 28480 0160-2261
A11C6 0140-0213 2 CAPACITOR-FXD 2000PF +-1% 300VDC MICA 72136 DM19F202F0300WV1CR
A11C7 0140-0213 CAPACITOR-FXD 2000PF +-1% 300WVDC MICA 72136 DM19F202F0300WV1CR
A11C8 0160-2055 1 CAPACITOR-FXD .01UF +80-20% 100WVDC CER 28480 0160-2055
A11C9 0121-0036 1 CAPACITOR-V TRMR-CER 5.5/18PF 350V 73899 DV11PR18A
A11C10 0180-0374 1 CAPACITOR-FXD 10UF +-10 20VDC TA 56289 150D1006X90200B2
A11C11 0160-2204 1 CAPACITOR-FXD 100PF -+5% 300WVDC MICA 93790 RDM15F101J3C
A11C12 0160-2199 1 CAPACITOR-FXD 30PF +-5% 300WVDC MICA 24840 0160-2199
A11C13 0180-0116 4 CAPACITOR-FXD 6.8UF +-10% 35VDC TA 56289 150D685X9035B2
A11C14 0180-0116 CAPACITOR-FXD 6.8UF+-10% 35VDC TA 56289 150D685X9035B2
A11C15 0180-1714 2 CAPACITOR-FXD 330UF+-10% 6VDC TA 56289 150D337X9006S2
A11C16 0180-1714 CAPACITOR-FXD 330UF+-10% 6VDC TA 56289 150D337X9006S2
A11C17 0180-0116 CAPACITOR-FXD 6.8UF +-10% 35VDC TA 56289 150D685X9035B2
A11C18 0180-0116 CAPACITOR-FXD 6.8UF+-10% 35VDC TA 56289 150D685X9035B2
A11C19 0180-0228 1 CAPACITOR-FXD 22UF +-10% 15VDC TA 56289 150D226X9015B2
A11C20 0160-2261 CAPACITOR-FXD 15PF +-5% 500WVDC CER 28480 0160-2261
A11C21 0160-2236 1 CAPACITOR-FXD 1PF +-.25PF 500WVDC CER 28480 0160-2236
A11C22 0180-2207 2 CAPACITOR-FXD 100UF +-10VDC TA 56289 150D107X9010R2
A11LC23 0180-2207 CAPACITOR-FXD 100UF +-10VDC TA 56289 1500107X9010R2
A11CR1 1901-0040 10 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901-0040
A11CR2 1901-0040 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901-0040
A11CR3 1901-0040 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901-0040
A11CR4 1901-0040 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901-0040
A11CR5 1901-0040 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901-0040
A11CR6 1901 0040 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901o0040
A11CR7 1901-0040 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901-0040
A11CR8 1901-0040 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901-0040
A11CR9 1901-0040 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901-0040
A11CR10 1901-0040 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901-0040
A11MP1 0340-0037 2 TERMINAL-STUD DBL-TUR PRESS-MTG 28480 0340-0037
0340-0039 2 TERMINAL BUSHING-TEFLON: MOUNTS IN 28480 0340-0039
A11MP2 0340-0037 TERMINAL-STUD DBL-TUR PRESS-MTG 28480 0340-0037
0340-0039 TERMINAL BUSHING-TEFLON: MOUNTS IN 28480 0340-0039
A11MP3 1430-0764 1 GEAR SPUR 28480 1430-0764
A11MP4 08640-00006 1 COVER, AUDIO OSCILLATOR 28480 08640-00006
A11MP5 08640-20090 4 SUPPORT, COVER AUDIO OSCILLATOR 28480 08640-20090
A11MP6 08640-00008 1 COVER, BACK A OSCILLATOR 28480 08640-00008
A11MP7 08640-20062 1 SPACER, BUSHING 28480 08640-20062
A11MP8 2200-0103 1 SCREW-MACH 4-40 .25-IN-LG PAN-HD-POZI 28480 2200-0103
A11MP9 0570-0111 1 SCREW-MACH 6-32 .37-IN-LG RD-HD-SLT 95987 N-632-3/8
A11MP10 2190-0004 1 WASHER-LK INTL T NO.-4 .115-IN-ID U1453 1904
A11MP11 2260-0009 1 NUT-HEX-W/LKWR 4-40-THD .094-THK .25A/F 28480 2260-0009
A11MP12 0403-0026 1 GLIDE: NYLON 28480 0403-0026
A11MP13 4040-0749 1 EXTRACTOR-PC BD BRN POLYC .062-BD-THKNS 28480 4040-0749
1480-0073 5 PIN:DRIVE 0.250" LG 00000 0BD
A11MP14 086640-20090 SUPPORT, LOWER, AUDIO OSCILLATOR 28480 08640-20090
A11MP15 08640-20090 SUPPORT, LOWER, AUDIO OSCILLATOR 28480 08640-20090
A11MP16 08640-20090 SUPPORT, LCWER, AUDIO OSCILLATOR 28480 08640-20090
A11Q1 1853-0020 2 TRANSISTOR PNP SI PD=300MW FT=150MHZ 28480 1853-0020
A11Q2 1854-0071 TRANSISTOR NPN SI PD-300MW FT=200MHZ 28480 1854-0071
A11Q3† 1853-0276 2 TRANSISTOR PNP SI TO-52 PD-3600MW 04713 MM3906
1200-0173 2 INSULATOR-XSTR TO-5 .075-THK 28480 1200-0173
A11Q4 1854-0351 2 TRANSISTOR NPN SI TO-18 PD=360MW 28480 1854-0351
A11Q5 1854-0003 TRANSISTOR NPN SI TO-39 PD=800MW 28480 1854-0003
A11Q6† 1854-0003 2 TRANSISTOR NPN SI TO-39 PD=800MW 28480 1854-0003
1200-0173 INSULATOR-XSTR TO-5 .075-THK 28480 1200-0173
A11Q7 1854-0351 TRANSISTOR NPN SI TO-18 PD=360MW 28480 185-0351
A11Q8 1853-0276 TRANSISTOR PNP SI TO-52 PD-360MW 04713 MM3906
A11Q9 1854-0071 TRANSISTOR NPN SI PD=300MW FT=200MHZ 28480 1854-0071
A11Q10 1853-0020 TRANSISTOR PNP SI PD=300MW FT=150MHZ 28480 1853-0020
A11Q11 1855-0062 1 TRANSISTOR J-FET N-CHAN (D-NODE SI 28480 1855-0062
41IQ12 1854-0071 TRANSISTOR NPN SI PD=3OOMW FT=200MHZ 28480 1854-0071
A11R1 0698-8294 2 RESISTOR 21.5M 1% .5W F TC=O+-100 28480 0698-8294
4llR2 0698 3453 3 RESISTOR 196K 1% .125W F TC=O+-100 16299 C4-1/8-TO-1963-F
,A113 0698-4508 1 RESISTOR 78.7K 1% .125W F TC=O+ 100 24546 C4-1/8-TO-7872-F
A11R4 0698-8294 RESISTOR 21.5M 1% .5W F TC=O+-100 28480 0698-8294
A11R5 0698-3451 1 RESISTOR 133K 1% .125W F TC=O+-100 16299 C4-1/8-1TO-1333-F
See introduction to this section for ordering information.
† SEE TABLES 7-1 AND 7-2, FOR BACKDATING.
6-25
