Model 8640B TM 9-4935-601-14-7&P
Table. 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
A12 08640 60003 RECTIFIER ASSY 28480 08640-60003
A12C1 0160-0168 5 CAPACITOR-FXD .1UF +-10% 200WVDC POLYE 56289 292P10492
A12C2 0160-0168 CAPACITOR-FXD .1UF +-10% 200WVDC POLYE 56289 292P10492
A12C3 0160-0168 CAPACITOR-FXD .1UF +-10% 200WVDC POLYE 56289 292P10492
A12C4 0160-0168 CAPACITOR-FXD .1UF +-10% 200WVDC POLYE 56289 292P10492
A12C5 0160-0168 CAPACITOR-FXD .1UF +-10% 200WVDC POLYE 56289 292P10492
A12CR1 1901-0418 20 DIODE-PWR RECT 400V 1.5A 04713 SR184612
A12CR2 1901-0418 DIODE-PWR RECT 400V 1.5A 04713 SR1846-12
A12CR3 1901-0418 DIODE-PWR RECT 400V 1.5A 04713 SR1846-12
A12CR4 1901-0418 DIODE-PWR RECT 400V 1.5A 04713 SR1846-12
A12CR5 1901-0418 DIODE-PWR RECT 400V 1.5A 04713 SR1846-12
A12CR6 1901-0418 DIODE-PWR RECT 400V 1.5A 04713 SR1846-12
A12CR7 1901-0418 DIODE-PWR RECT 400V 1.5A 04713 SR1846-12
A12CR8 1901-0418 DIODE-PWR RECT 400V 1.5A 04713 SR1846-12
A12CR9 1901-0418 DIOOE-PWR RECT 400V 1.5A 04713 SR1846-12
A12CR10 1901-0418 DIODE-PWR RECT 400V 1.5A 04713 SR1846-12
A12CR11 1901-0418 DIODE-PWR RECT 400V 1.5A 04713 SR1846-12
A12CR12 1901-0418 DIODE-PWR RECT 400V 1.5A 04713 SR1846-12
A12CR13 1901-0418 DIODE-PWR RECT 400V 1.5A 04713 SR1846-12
A12CR14 1901-0418 DIODE-PWR RECT 400V 1.5A 04713 SR1846-12
A12CR15 1901-0418 DIODE-PWR RECT 400V 1.5A 04713 SR1846-12
A12CR16 1901-0418 DIODE-PWR RECT 400V 1.5A 04713 SR1846-12
A12CR17 1901-0418 DIODE-PWR RECT 400V 1.5A 04713 SR1846-12
A12CR18 1901-0418 DIODE-PWR RECT 400V 1.5A 04713 SR1846-12
A12CR19 1901-0418 DIODE-PWR RECT 400V 1.5A 04713 SR1846-12
A12CR20 1901-0418 DIODE-PWR RECT 4OOV 1.5A 04713 SR1846-12
A12MP1 0403-0026 2 GLIDE:NYLON 28480 0403-0026
A12Q 1884-0012 6 THYRISTOR-SCR JEDEC 2N3528 02735 2N3528
A12R81 0757-0401 8 RESISTOR 100 1% .125W F TC=0+-100 24546 C4-1/8-TO-101-F
A12R82 0698-3447 6 RESISTOR 422 1% .125W F TC=0+-100 16299 C4-1/8-TO-422R-F
A12R3 0757-0199 1 RESISTOR 21.5K 1% .125W F TC=0+-100 24546 C4-1/8-TO-2152-F
A12R4 0757-0442 18 RESISTOR 10K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A12R5 0757-0442 RESISTOR 10K 1%2 .125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A12R6 0757-0442 RESISTOR 10K 1%.125W F TC=0+-100 24546 C4-1/87TO-1002-F
A12R7 0757-0442 RESISTOR 10K 1S .125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A12VR1 1902-3393 1 DIODE-2NR 75V 5% DO=7 PO-.4W TC-+.077% 04713 SZ 10939-434
A13 08640-60002 1 MODULATION/METERING MOTHER BOARD ASSY 28480 08640=60002
A13C1 0180-2208 5 CAPACITOR-FXD 220UF+-10% 10VDC TA 56289 150D227X901052
A13C2 0180-2208 CAPACITOR-FXD 220UF+-10% 10VDC TA 56289 1500227X9010S2
A13C3 0180-2208 CAPACITOR-FXD 220UF+-10% 10VDC TA 56289 1500227X9010S2
A13C4 0180-2208 CAPACITOR-FXD 220UF+-10% 10VDC TA 56289 1500227X9010S2
A13J1 1250-0257 3 CONNECTOR-RF SMB M PC 28480 1250-0257
A13J2 1251-3055 2 CONNECTOR STRIP:8 MALE CONTACT 74868 221-70
A13J3 1250-0257 CONNECTOR-RF SMB N PC 28480 1250-0257
A13J4 1250-0257 CONNECTOR-RF SMB M PC 28480 1250-0257
A13J5 1251-3055 CONNECTOR STRIP:8 MALE CONTACT 74868 221-70
A13MP1 0403-0026 GLIDE:NYLON 28480 0403-0026
A13MP2 08640-20211 1 GUIDE. CONNECTOR 28480 08640-20211
A13MP3 08640-40063 GUIDE, SLIDE SWITCH 28480 08640-40063
A13R1 0757-0004 1 RESISTOR 860 1% 5W F TC=0+-100 19701 MF7C1/2-TO-861-F
A13R2 0757-0443 1 RESISTOR 11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1102-F
A13R3 2100-1986 1 RESISTOR-TRMR 1K 10% TOP-ADJ 1-TURN 30983 ETSOW102
A13R4 0757-0460 2 RESISTOR 61.9K 1% .125W F TC=0+-100 24546 C4-1/8-TO-6192-F
A13R5 0757-0460 RESISTCR 61.9K 1% .125W F TC=0+-100 24546 C4-1/8-TO-6192-F
A13R6 08640-60152 1 SWITCH, SLIDE 4R, PC 28480 08640-60152
5020-3440 2 SPRING:DETENT 28480 5020-3440
08640-40063 3 GUIDE, SLIDE SWITCH 28480 08640-40063
A13S2 08640-60153 1 SWITCH, SLIDE 3R, PC 28480 08640-60153
5020-3440 SPRING:DETENT 28480 5020-3440
5040-0319 1 SLIDE:3 RGW. 12 POSITION 28480 5040-0319
08640-40063 GUIDE, SLIDE SWITCH 28480 08640-40063
A13XA11 1251-2571 8 CONNECTOR-PC EDGE 15-CONT/ROW 1-ROW 26742 91-6915-0702-00
A13XA15 1251-2035 1 CONNECTOR-PC EDGE 15-CONT/ROW 2-ROWS 71785 252-15-30=3D0
A13XA2 1251-2571 CONNECTOR-PC EDGE 15-CONT/ROW 1-ROW 26742 91-6915-0702-00
A13XA3A4 1251-0472 1 CONNECTOR-PC EDGE 6-CONT/ROW 2-ROWS 71785 252-06-30-300
