Model 8640B TM 9-4935-601-14-7&P
Table. 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
A13XA4 1251-2571 CONNECTOR-PC EDGE 15-CONT/ROW 1-ROW 26742 91-6915-0702-00
A13XA5 1251-2571 CONNECTOR-PC EDGE 15-CONT/ROW 1-ROW 26742 91-6915-0702-00
A13XA7 1251-2571 CONNECTOR-PC EDGE 15-CONT/ROW 1-ROW 26742 91-6915-0702-00
A13XA8A3 5060-0109 1 CONNECTOR:15 CONTACTS 28480 5060-0109
A14 5060 9409 1 LINE MODULE WITH FILTER, JADE GRAY 28480 5060-9409
A14MP1 7120-4264 1 LABEL, INFO LINE V.+5-10%; 48-440 28480 7120-4264
414P1 5020-8122 1 LINE VOLTAGE SELECTION CARD 28480 5020-8122
A15 08640-60018 1 RISER ASSY 28480 08640-60018
A15MP1 0403-0153 2 GUIDE-PC BD BRN POLYC .062-BD-THKNS I-LG 28480 0403-0153
A15MP2 0403-0154 1 GUIDE-PC BF RED POLYC .062-BD-THKNS I-LG 28480 0403-0154
A15MP3 0403-0155 1 GUIDE-PC BD CRN POLYC .062-BD-THKNS I-LG 28480 0403-0155
A15XA17 1251-3308 1 CONNECTOR-PC EDGE 15-CONT/ROW 2-ROWS 71785 252-12-30-032
A16 08640-60119 1 FAN MOTOR ASSY 28480 08640-60119
A16B1 3140G0490 1 MOTOR BRUSHLESS 10VDC 2550-RPM 3H768 1AD3001-OA
A16P1 1251-0198 1 CONNECTOR-PC EDGE 6-CONT/ROW 2-ROWS 71785 251-06-30-261
5040-0327 1 HOOD:CCNNECTOR 28480 5040-0327
A17 0B64* 60001 1 POWER SUPPLY MOTHER BOARD ASSY 28480 08640-60001
A17XA12 1251-2034 3 CONNECTOR-PC EDGE 10-CONT/ROW 2-ROWS 71785 252-10-30-300
A17XA18 1251-2571 CONNECTOR-PC EDGE 15-CONT/ROW 1 ROW 26742 91-6915-0702-00
A17XA20 1251-2571 CONNECTOR-PC EDGE 15-CONT/ROW 1-ROW 26742 91-6915-0702-00
A17XA22 1251-2571 CONNECTOR-PC EDGE 15-CONT/ROW 1-ROW 26742 91-6915-0702-00
A17XA24 1251-2034 CONNECTOR-PC EDGE 10-CONT/ROW 2-ROWS 71785 252-1030-300
A17XA26 1251-2034 CONNECTOR-PC EDGE 10-CONT/ROW 2-ROWS 71785 252-10-30-300
A18 08640-60004 1 REGULATOR & FAN DRIVER ASSY, -5.2V 28480 08640-60004
A18C1 0180-0229 5 CAPACITOR-FXD 33UF+-10% 10 VDC TA 56289 150D336X9010B2
A18C2 0160-3534 4 CAPACITOR-FXD 510PF +-5% 100WVDC MICA 28480 0160-3534
A18C3 0180-2214 1 CAPACITOR-FXD 90UF+-75-10% 16VDC AL 56289 300906G016CC2
A18C4 0180-0197 3 CAPACITOR-FXD 2.2UF+-10 20% VDC TA 56289 1500225X9020A2
A18C5 0160-2055 1 CAPACITOR-FXD .01UFF +80-20% 100WVDC CER 28480 0160-2055
A18CR1 1901-0040 21 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901-0040
A18CR2 1901-0025 4 DIODE-GEN PRP 100V 200MA DO-7 28480 1901-0025
A18CR3 1901-0025 DIODE-GEN PRP 100V 200MA DO-7 28480 1901-0025
A1BCR4 1901-0040 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901-0040
A18CR5 1901-0040 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901-0040
A18CR6 1901-0159 5 DIODEPWR FECT 400V 750MA DO-41 04713 SR1358-4
A18CR7 1901-0040 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901-0040
A18CR8 1901-0040 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901-0040
A18CR9 1901-0049 2 DIODE-PWR RECT 50V 750MA DO-29 28480 1901-0049
A18CR10 1901-0049 DIODE-PWR RECT 50V 750MA DO-29 28480 1901-0049
A18CR11 1901-0040 DIODE=SWITCHING 30V 50MA 2NS 00=35 28480 1901-0040
A18CR12 1901-0050 6 DIODE-SWITCHING 80V 200MA 2NS 00-7 28480 1901-0050
A18DS1 1990-0326 5 LED-VISIBLE 28480 1990-0326
A18F1 2110 0425 1 FUSE 2A 125V SLO-BLO .25X.27 71400 GMW 2A
A18MP1 4040-0752 2 EXTRACTOR-PC 8D YEL POLYC .062-BD-THKNS 28480 4040-0752
1480-0073 9 PIN:DRIVE 0.250" LG 00000 OBD
A18Q1 1853-0020 2 TRANSISTOR PNP SI PD=300MW FT=150MHZ 28480 1853-0020
A18Q2† 1854-0039 4 TRANSISTOR NPN 2N3053 SI TO-5 PD=1W 04713 2N3053
1200-0173 10 INSULATOR-XSTR TO-S .075-THK 28480 1200-0173
A18Q3 1884-0012 THYRISTOR-SCR JEDEC 2N3528 02735 2N3528
A18Q4 1854-0003 1 TRANSISTOR NPN SI TO-39 PD8OOMW 28480 1854-0003
A18Q5† 1853-0027 4 TRANSISTOR PNP SI TO-39 PD-1W FT=100MHZ 28480 1853-0027
1200-0173 INSULATOR-XSTR TO-5 .075-THK 28480 1200-0173
A18Q6 1853-0050 4 TRANSISTCR PNP SI TO-18 PFD360MW 28480 18530050
A18Q7† 1853-0027 TRANSISTOR PFP SI TO-39 PD-1W FT=100MHZ 28480 1853-0027
1200-0173 INSULATOR-XSTR TO-5 .075-THK 28480 1200-0173
A18Q8 1853-0050 TRANSISTOR PNP SI TOB1 PD=360MW 28480 1853-0050
A18Q9 1853-0050 TRANSISTOR PNP SI TO-18 PD=36OMW 28480 1853-0050
A18Q10† 1853-0027 TRANSISTOR PNP SI TO-39 PD-1W FT=100MHZ 28480 1853-0027
1200-0173 INSULATOR-XSTR TO-5 .075-THK 28480 1200-0173
A18Q11 1853-0050 TRANSISTOR PNP S1 TO-18 PD=360MW 28480 1853-0050
See introduction to this section for ordering information.
† SEE TABLES 7-1 AND 7-2, FOR BACKDATING.
6-29
