Model 8640B TM 9-4935-601-14-7&P
Table. 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
418012† 1853-0027 TRANSISTOR PNP SI T70-39 PD=1W FT=100MHZ 28480 1853-0027
1200-0173 INSULATOR-XSTR TO-5 .075-THK 28480 1200-0173
A18R1 0757-0317 3 RESISTOR 1.33K 1% .125W F TC=0+-100 24546 C4-1/8 TO-1331-F
A18R2 2100-3123 4 RESISTOR-TRMR 500 10% C SIDE-ADJ l7-TURN 32997 3006P-1-501
A18R3 0757-0278 RESISTOR 1.78K 1% .125W F TC=-0+-100 24546 C4-1/8-TO-1781-F
A18R4 0683-0475 1 RESISTOR 4.7 5% .25W FC TC-400/+500 01121 C847G5
A18R5 0757-0420 4 RESISTOR 750 1% .125W F TC=0+-100 24546 C4-1/8-TO-751-F
A18R6 06983440 3 RESISTOR 196 1% .125W F TC=0+-100 16299 C4-1/8-TO-196R-F
A18R7 0757-0420 RESISTOR 750 1% .125W F T=-0+-100 24546 C4-1/8-TO-751-F
A18R8 0698-3161 1 RESISTOR 38.3K 1% .125W F TC=0+-100 16299 C4-1/8-TO-3832-F
A18R9 0811-2813 3 RESISTOR 1 5% .75W PW TC=0+-50 91637 RS1/2-T2-IRO-J
A18R10 0757-0316 2 RESISTOR 42.2 1% .125W F TC=0+-100 24546 C4-1/8-TO-422Z-F
A18R11 0757-0317 RESISTOR 1.33K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1331-F
A18R12 0757-0397 5 RESISTOR 68.1 1% .125W F TC=0+-100 24546 C4,1/8-TO-68R1-F
A18R13 0698-3447 RESISTOR 422 1% .125W F TC=0+-100 16299 C4-1/8-TO-422R-F
A18R14 0757-0290 3 RESISTOR 6.19K 1% .125W F TC=0+-100 19701 MF4C1/8-TO-6191-F
A18R15 0757-0442 RESISTOR 10K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A18R16 0811-1553 1 RESISTOR .68 52 2% PW TC=0+-800 75042 BWH2=11/16-J
A18R17 0698-3438 RESISTOR 147 1% .125W F TC-0+-100 16299 C4-1/8-TO-147R-F
A18R18 0698-3438 RESISTOR 147 1% .125W F TC=0+-100 16299 C4-1/7-TO-147R-F
A18R19† 0698-7246 2 RESISTOR 2.61K 2% .05W F TC=0+-100 24546 C3-1/8-TO-2611G
A18TP1 0360-1514 43 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A18TP2 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A18TP3 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A18TP4 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A18TP5 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A18TP6 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A18U1 1826-0010 5 IC UA 723 V RGLTR 07263 723HM
A18VR1 1902-3005 2 DIODE-ZNR 2.43V 5% DO-7 PD=.4W TC=-.0762 04713 SZ 10939-5
A18VR2 1902-3094 1 DIODE-ZNR 5.11V 2% DO-7 PD=.4W TC=-.009% 04713 SZ 10939-99
A18VR3 1902-0049 2 DIODE-ZNR 6.19V 5% DO-7 PD=.4W TC=+.0222 04713 SZ 10939-122
A18XF1A 1251-2313 10 CONNECTOR-SOL CONT SKT .04-DIA 00779 3-332070-5
A18XF18 1251-2313 CONNECTOR-SGL CONT SKT .04-DIA 00779 3-332070-5
A19 NOT ASSIGNED
A20 08640-60005 1 REGULATOR ASSY, +5.2V & +44.6V 28480 08640-60005
A20C1 0160-0153 1 CAPACITOR-FXD 1000PF +-10% 200WVDC POLYE 56289 292P10292
A20C2 0180-0229 CAPACITOR-FXD 33UF +-10% 10VDC TA 56289 150D336X9010B2
A20C3 0180-0234 1 CAPACITOR-FXD; 33UF+-20% 75VDC TA-MET 56289 109D336X0075F2
A20C4 0180-0228 1 CAPACITOR'FXD 22UF+-10% 15VDC TA 56289 1500226X9015B2
A20C5 0160-0300 1 CAPACITOR-FXD 2700PF+-10% 200WVDC POLYE 56289 292P27292
A20C6 0180-2208 CAPACITOR-FXD 220UF+-10% 10VDC TA 56289 1500227X901052
A20C7 0180-0229 CAPACITOR-FXD 33UF+-10% 10VOC TA 56289 1500336X9010B2
A20C8 0160-3094 6 CAPACITOR-FXD .1UF +-10% 100WVDC CER 28480 0160-3094
A20CR1 1901-0159 DIODE-PWR RECT 400V 750MA DO-41 04713 SR1358-4
A20CR2 1901-0050 DIODE-SWITCHING 80V 200MA 2NS D0-7 28480 1901-0050
A20CR3 1901-0159 DIODE-PWR RECT 400V 750MA D0-41 04713 SR1358-4
A20CR4 1901-0050 DIODE-SWITCHING 8OV 200MA 2NS DO-7 28480 1901-0050
A20CR5 1901-0050 DIODE-SWITCHING 8OV 200MA 2NS DO-7 28480 1901-0050
A20DS1 1990-0326 LED-VISIBLE 28480 1990-0326
A20DS2 1990-0326 LED-VISIBLE 28480 1990-0326
A20F1 2110-0332 1 FUSE 3A 125V .25X.27 71400 GMW 3
A20F2 2110-0047 1 FUSE 1A 125V .25X.27 71400 GMW-1
A20MP1 4040-0748 2 EXTRACTOR-PC 80 BLK POLYC .062-80-THKNS 28480 4040-0748
1480-0073 PIN:DRIVE 0.250" LG 00000 OBD
A20MP2 4040-0753 2 EXTRACTOR-7PC 80 GRN POLYC .062-BD-THKNS 28480 4040-0753
1480-0073 PIN:DRIVE 0.250" LG 00000 OBD
A20Q1 1884-0012 THYRISTOR-SCR JEDEC 2N3528 02735 2N3528
A20Q2† 1854-0039 TRANSISTOR NRN 2N3053 S1 70-5 PD=1W 04713 2N3053
1200-0173 INSULATOR-XSTR TO-5 .075-THK 28480 1200-0173
A20Q3† 1854 0022 1 TRANSISTOR NPN SI TO-39 PD=700MW 07263 S17843
1200-0173 INSULATOR-XSTR ID-5 .075-THK 28480 1200-0173
A20Q4† 1853-0038 1 TRANSISTOR PNP SI TO-39 PD=1W FT=100MHZ 28480 1853=0038
1200-0173 INSULATOR-XSTR ID-5 .075-THK 28480 1200-0173
A20Q5 1853-0020 TRANSISTOR PIP SI PD-300MW FT=150MHZ 28480 1853-0020
A20Q6 1854-0023 1 TRANSISTOR NPN SI TO-18 PD=360MW 28480 1854-0023
A20Q7 1884-0012 TIHYRISTOR-SCR JEDEC 2N3528 02735 2N3528
A20R1 0698-3160 2 RESISTOR 31.6K 1% .125W F TC=0+-100 16299 C4-1/8-TO-3162-F
A20R2 0698-3438 RESISTOR 147 1% .125W F TC=0+-100 16299 C4-1/8-TO-147R-F
A20R3 0757-0462 1 RESISTOR 75K 1%.125W F TC=0+-100 24546 C4-1/8-TO-7502-F
A20R4 0698-0083 6 RESISTOR 1.96K 1% .125W F TC=0+-100 16299 C4-1/8-TO-1961-F
A20R5 0698-3407 1 RESISTOR 1.96K 1% .5W F TC=0+-100 24546 NA6
See introduction to this section for ordering information.
† SEE TABLES 7-1 AND 7-2, FOR BACKDATING.
6-30
