VAR8 Menu Description
Ref. Item Description/Possible Settings
116 Control
Applicable when the selected contact is configured for Routing. Having selected
this option the sub-menus ‘Latching’, ‘Busy=on’, and ‘DVA-Full’ are displayed for
routing control configuration.
117 Clear-all
Applicable when the selected contact is configured for Routing. Enables the user
to clear any route programmed for the selected contact.
118 Analogue Access to Remote I/O Unit Analogue Input configuration functions.
119 Digital In Access to Remote I/O Unit Digital Input (contact) configuration functions.
120 Digital Out
Enables the user to assign each Remote I/O digital output to correspond to the
busy state of any Router output or group of outputs. It is possible to configure
which input, or group of inputs, will cause the ‘busy’ indication to be given on a
particular Router output.
Possible digital outputs: 1 to 12
121 Inputs
Defines a gain to be applied to the input audio, in respect of any output to which
it may be routed.
Possible values:
–63dB to 0dB (1dB steps)
Default value:
‘–20dB’
122 Outputs
Defines a gain to be applied to the input audio, separately for each output to
which it may be routed.
Possible values:
–40dB to 0dB (1dB steps)
Default value:
‘0dB’
123 Latching Defines whether the selected contact is used to both make and clear the route.
• ‘Not Latched’: activation of the contact initiates the route, and release of the
contact terminates it.
• ‘Latched’: a reset contact is also defined; in this configuration activation of the
first contact initiates the route, and activation of the reset contact terminates it
(provided that the first contact has been released).
If ‘Latched’ has been chosen, the user can identify the contact that will act as
the reset contact.
Default value:
‘Not Latched’
124 Busy=On
Defines whether or not this route should cause busy indication on the LEDs
associated with microphone zone select buttons.
Possible values:
‘On’ or ‘Off’
Default value:
‘On’
125 DVA-Full
Defines whether, when the route is terminated, the DVA shall cease playing
immediately or play until its end.
Possible values:
‘DVA-Full’ or ‘DVA-Part’
Default value:
‘DVA-Full’
126 Analogue channel=nn
Enables user to scroll through the Remote I/O Unit Analogue Input list for
selection. Having chosen an input sub-menus are displayed to define the use of
the channel.
Where: nn=1 to 12
127 Contact#nn
Enables the user to scroll through Digital Input contact list for the Remote I/O
Unit.
Where: nn=1 to 12
