ASL INTERCOM VAR8 User Manual

VAR8 and Variants Operation, Commissioning, Fault Finding, and Maintenance Guide
sue: 02 complete, approved
-
Is
Page 68 of 166 Page 68 of 166
11.2 Music Input Emergency Class Configuration 11.2 Music Input Emergency Class Configuration
The Emergency Class is only relevant in networked units, and is used by the ACU and Fire Microphones
connected to an ACU to indicate the emergency DVA message status of the zone group configured for a
zone select button via its red and green LEDs. See Section “10.2 DVA Input Emergency Class
Configuration” for further details.
The Emergency Class is only relevant in networked units, and is used by the ACU and Fire Microphones
connected to an ACU to indicate the emergency DVA message status of the zone group configured for a
zone select button via its red and green LEDs. See Section “10.2 DVA Input Emergency Class
Configuration” for further details.
To Modify the Music Input Emergency Class: To Modify the Music Input Emergency Class:
3. Select the Music input, and then modify its emergency class as required. 3. Select the Music input, and then modify its emergency class as required.
Note that the in addition to the unbalanced input (Input 9), a balanced input can be used for background
music.
Note that the in addition to the unbalanced input (Input 9), a balanced input can be used for background
music.
Menu: ConfigurationÆSystemÆRouterÆInputsÆMic/LineÆI/P #<nn>ÆCtrlÆClass Menu: ConfigurationÆSystemÆRouterÆInputsÆMic/LineÆI/P #<nn>ÆCtrlÆClass
On networked units, for correct indication of the emergency DVA message status on the
ACU’s front panel, as described in Section “10.2 DVA Input Emergency Class
Configuration”, the background music must be set to ‘Non Emergency’ as specified in the
system default settings.
Changes to the system default settings may result in an inappropriate indication of the
status of the zone or group of zones.
!
!
